DSK‐2H
Quick Star
Quick Star
Quick Star
Quick StarQuick Start Guide
t Guide
t Guide
t Guide t Guide
800.AVI.2131
Tel: (818) 503-6200 Fax: (818) 503-6208
|
|
|
||
11651 Vanowen St. North Hollywood, CA 91605
SmartAVI.com
PART NO. QTY DESCRIPTION
DSK-2H-S 1 2-Port HDMI USB KVM
SWITCH
1 Quick Start Guide
WHAT’S IN THE BOX
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages
in connection with the furnishing, performance or
use of this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
20170206
Control and manage USB
keyboard-mouse functions on two
computers with HDMI Monitors
2-P
2-P
2-P
2-P 2-Por
or
or
orort HDMI USB
t HDMI USB
t HDMI USB
t HDMI USBt HDMI USB KVM Switch
KVM Switch
KVM Switch
KVM Switch KVM Switch
TECHNICAL SPECIFICATIONS
VIDEO
Video Format HDMI 1.3a, HDCP Compliant
Video Input (2) HDMI Male
Video Output (1) HDMI Female
Resolution 3840x2160 @ 30Hz
Auto-Scan In-
terval
10 seconds
Audio Supports HD Audio via HDMI
CONTROL
Push Button
Switch between sources 1 &
2
Hot Keys Via Keyboard
LEDs Blue for PC Selection
Green indicates PC ON-Line
USB
Input (2) USB Type A Male
Output (2) USB Type A Female
Signal Type USB 1.1 & 2.0
OTHER
Dimensions
2.56” x 3.35” x .99”
(65 x 85 x 25 mm)
Weight .728 lbs (330 g)
Power
Powered by USB PC connec-
tion
Operating
Temp.
+23 to +95°F (-5 to +35°C)
Storage Temp. -4 to 185°F (-20 to 85°C)
Humidity 5 to 90% (No Condensation)
Problemløsning Smart-AVI DSK-2H
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 65 mm |
| Dybde: | 85 mm |
| Højde: | 25 mm |
| Produktfarve: | Black, Grey |
| Indbygget skærm: | Ingen |
| HD-type: | 4K Ultra HD |
| Opbevaringstemperatur (T-T): | 23 - 95 °C |
| Relativ luftfugtighed ved drift (H-H): | 5 - 90 % |
| Antal HDMI-porte: | 1 |
| Driftstemperatur (T-T): | -5 - 35 °C |
| Maksimal opløsning: | 3840 x 2160 pixel |
| USB-stik type: | USB Type-A |
| Stativ-montering: | Ingen |
| Antal kontrollerede computere: | 2 |
| Tastatur porttype: | USB |
| Mus porttype: | USB |
| Video porttype: | HDMI |
| Dataoverførselshastighed (maks.): | 5.4 Gbit/sek. |
| Video båndbredde: | 30 Hz |
