Advanced HDMI KVM Extenders
via x and FiberCAT
ELEVATE YOUR CONNECTIVITY
WITH HDMI KVM EXTENDERS
VIA CATX AND FIBER
Quick Start Guide
VIDEO
Format HDMI
Max Resolution 3840x2160 @ 30Hz
Input Cable Length Up to 20 ft
Output Cable Length Up to 20 ft
ETHERNET
Format RJ45 and/or SFP Fiber
Supported Cable
Length
300ft/100meters via CATx or 10km
via Fiber
USB
Signal Type (2) HID KM Ports, (2) USB 2.0 Ports
User Console
Interface
(2) USB Type-A for keyboard and
mouse connection only
(2) USB Type-A for USB 2.0 devices
AUDIO
Input Stereo 3.5mm Female
Output Stereo 3.5mm Female
POWER
Power Requirements 5V DC, 2A (minimum) power adapter
with center-pin positive polarity
ENVIRONMENT
Operating Temp 32° to 104° F (0° to 40° C)
Storage Temp -4° to 140° F (-20° to 60° C)
Humidity 0-80% RH, non-condensing
MEASUREMENTS
Dimension 8.5” W x 4” L x 1.8” H
Weight 1lb 10oz
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
888.994.7427, 702.800.0005
2917 E Alexander Rd.
North Las Vegas, NV 89030
SmartAVI.com
TECHNICAL SPECIFICATION
DFX-XT-2P
WHAT’S IN THE BOX
PART NO. DESCRIPTIONQ-TY
Transmitter 1 Advanced HDMI KVM
Transmitter via CATx/Fiber
Receiver 1 Advanced HDMI KVM
Receiver via CATx/Fiber
Power Supply 2 PS5VDC2A
Quick Start Guide 1
