Siemens LC97FLP60I Brugsanvisning
Her er Siemens LC97FLP60I (Emhætte) brugervejledning. 3 sider på sprog Engelsk med en vægt på 0.5 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/3
1/3
iQ500, wall-mounted cooker hood, 90
cm, clear glass black printed
LC97FLP60I
The wall-mounted chimney hood: mount it on the wall, giving
you complete freedom in your kitchen planning.
✓LED light: Optimal visibility and atmosphere when cooking.
✓Calms the cooking process - Extremely quiet
✓Pleasantly quiet - motor.
✓Intensive setting with automatic after revert setting
Features
Technical Data
Typology : Wall-mounted
Length electrical supply cord : 130 cm
Height of product, without chimney : 430 mm
Net weight : 21.7 kg
Type of control : Electronic
Number of speed settings : 3-stage + 2 intensive
Maximum output air extraction : 394 m³/h
Boost position output recirculating : 404 m³/h
Maximum output recirculating air : 249 m³/h
Boost position air extraction : 717 m³/h
Number of lights : 2
Noise level : 57 dB(A) re 1 pW
Diameter of air outlet : 120 / 150 mm
Grease filter material : Washable aluminium
Odour filter : No
Operating Mode : Convertible
Delay Shut off modes : 10 min
Optional accessories : HZG9AS00S, LZ00XXP00, LZ10AFR00,
LZ10AFS00, LZ10AXK50, LZ10AXL50, LZ11AFB16, LZ11AFI16,
LZ11AFV16, LZ11AXC56, LZ11AXE61, LZ31XXB16
Type of lamps used : LED
Grease filter type : Multilayer cassette
Connection Rating : 143 W
Fuse protection : 10 A
Voltage : 220-240 V
Frequency : 50; 60 Hz
Installation typology : Wall-mounted
Material body : Glass, Lacquered
Dimensions of the product, with chimney (if exists) (in) : / x x
Dimensions of the packed product : 21.25 x 29.13 x 40.94
Net weight : 48.000 lbs
Gross weight : 64.000 lbs
Motor location : Integrated motor in hood body
No-return airflow flap : Yes
Length electrical supply cord : 130 cm
Dimensions of the product, with chimney (if exists) : 500 x 890.0 x
263.0 mm
Dimensions of the packed product (HxWxD) : 540 x 740 x 1040 mm
Net weight : 21.7 kg
Gross weight : 29.0 kg
'!2E20AD-ijheif!
Manufactured by <BSH Legal Name> under Trademark License of Siemens AG
