Side 1/8
MZ2352SRB
IN-DASH INSTALLATION KIT FOR SELECT
2007-09 MERCEDES BENZ SLK VEHICLES(R171)
(for amplied vehicles w/ 5 pin connector)
This premium installation kit is for 2007-09 Mercedes Benz SLK vehicles with ber amplifer and 5 pin
connector. Included are all the parts you need to mount your car stereo or CD into your vehicle’s dash.
Refer to individual instruction in this manual to remove your vehicle’s factory radio and assemble the kit
© 2018 SCOSCHE INDUSTRIES, INC
Table of Contents
If you have any further questions, call our toll free technical help line: or visit us online at 1-800-363-4490 x1 www.scosche.com/contact
This MZ2352SRB instruction manual is based on carefully documented data and research. Scosche
Industries Inc. cannot be held responsible for discrepancies/inconsistencies that may occur due to
the vehicle manufacturing changes or options, or damages that may occur in the vehicle during the
installation of components while using this manual.
INTRODUCTION / PRELIMINARY
LIABILITY DISCLAIMER
1. Cover Page
2. About / Disassembly
3. Disassembly (con’t)
4. Wiring Codes / SWC Codes
5. SWC Samples/ SWC Controls
6. LPMZ35 Interface Wiring Diagram
7. Kit Assembly
8. Notes
MZ2352SRB 04/18
Custom Manufactured in China
