1. List of Parts
•The provided accessories may vary depending on the model.
1
Remote Control & Batteries (AAA x 2)
2
Power Cord
3
Warranty Card / Quick Setup Guide / Regulatory Guide
(Not available in some locations)
4
Data Cable (Not available in some locations)
5
Antenna adapter (Not available in some locations)
2. The Remote Control
Installing batteries into the Remote Control
–The images, buttons, and functions of the
remote control may differ with the model
or geographical area.
–If you use the remote control that comes
with your TV to control another TV, some
functions may not operate normally.
3. Wall Mount Kit Specifications (VESA)
Install your wall mount on a solid wall, perpendicular to the floor. When attaching to other building materials, please contact
your nearest dealer. If installing on a ceiling or slanted wall, TV may fall and result in severe personal injury.
•The wall mount kit is not supplied, but sold separately.
•Standard dimensions for wall mount kits are shown in the table below.
•Samsung wall mount kits contain a detailed installation manual. All parts necessary for assembly are provided.
Do not install your wall mount kit while your TV is turned on. This may result in personal injury from electric shock.
•Do not use screws that are longer than the standard dimension or do not comply with the VESA standard screw
specifications. Screws that are too long may cause damage to the inside of the TV set.
•For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ
depending on the wall mount specifications.
•Do not fasten the screws too firmly. This may damage the product or cause the product to fall, leading to personal injury.
Samsung is not liable for these kinds of accidents.
•Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or
when the consumer fails to follow the product installation instructions.
•Do not mount the TV at more than a 15 degree tilt.
•Always have two people mount the TV onto a wall.
Wall mount
bracket
TV
C
•The Product shape may differ depending on the model.
TV size in
inches
VESA screw hole specs
(
* ) in millimeters
(mm) (mm) (mm)
C ( Standard Screwmm) Quantity
43
200 x 200
379.3 90.4 262.0
20-22 M8 4
50 148.7455.7 292.3
55 512.7 205.2 298.9
65 522.5 225.1 303.0400 x 300
75 633.9 230.9400 x 400 324.2
4. The Connection Panel
HDD
ARC
ANT IN
USB
HDMI
LAN
DATA
BACK OF TELEVISION
Quick Setup Guide
To register this product please visit www.samsung.com
5. Installing the LED TV Stand
Assembling the Stand and Components
When installing the stand, use the provided components and parts.
Stand
1
R
2 3
43″
75″
50-65″
4
NOTE
•Make sure to distinguish between the front and back of each component when assembling them.
•Make sure that at least two persons lift and move the TV.
6. Specifications
Model Name HG43CU700** HG50CU700** HG55CU700**
Display Resolution 3840 x 2160 3840 x 2160 3840 x 2160
Screen Size
Diagonal
Measured Diagonally
43˝ Class
42.5 measured diagonally
50˝ Class
49.5 measured diagonally
55˝ Class
54.6 measured diagonally
Sound (Output) 20 W 20 W 20 W
Dimensions (W x H x D)
Body
With stand
963.9 x 558.9 x 59.6 mm
963.9 x 627.8 x 192.5 mm
1116.8 x 644.2 x 59.9 mm
1116.8 x 719.1 x 250.2 mm
1230.5 x 707.2 x 59.9 mm
1230.5 x 783.3 x 250.2 mm
Weight
Without Stand
With Stand
8.1 kg
8.3 kg
11.4 kg
11.6 kg
13.9 kg
14.2 kg
Model Name HG65CU700** HG75CU700**
Display Resolution 3840 x 2160 3840 x 2160
Screen Size
Diagonal
Measured Diagonally
65˝ Class
64.5 measured diagonally
75˝ Class
74.5 measured diagonally
Sound (Output) 20 W 20 W
Dimensions (W x H x D)
Body
With stand
1449.4 x 830.3 x 59.9 mm
1449.4 x 906.6 x 282.1 mm
1673.2 x 958.2 x 59.9 mm
1673.2 x 1047.9 x 341.1 mm
Weight
Without Stand
With Stand
20.6 kg
20.9 kg
30.4 kg
30.8 kg
Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
50 °F to 104 °F (10 °C to 40 °C)
10 % to 80 %, non-condensing
-4 °F to 113 °F (-20 °C to 45 °C)
5 % to 95 %, non-condensing
•This device is a Class B digital apparatus.
•Design and specifications are subject to change without prior notice.
•For information about the power supply, and more information about power consumption, refer to the information on the
label attached to the product.
–On most models, the label is attached to the back of the TV. (On some models, the label is inside the cover terminal.)
•To connect a LAN cable, use a CAT 7 (*STP type) cable for the connection. (100/10 Mbps)
* Shielded Twisted Pair
•Your TV and its accessories may look different than the product images presented in this manual, depending on the model.
•All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the
dimensions before installing your TV. Not responsible for typographical or printed errors.
•Download the user manual from the following Samsung Website for further details. https://www.samsung.com
