System Power Amplifier (SPA)
Installation Guide
SPA2-60 Amplifier SPA4-60 Amplifier
SPA2-200 Amplifier SPA4-100 Amplifier
EXPLANATION OF SYMBOLS
The term “WARNING!” indicates instructions regarding personal safety. If the instructions are not followed the result may be bodily injury or death.
The term “CAUTION!” indicates instructions regarding possible damage to physical equipment. If these instructions are not followed, it may result in
damage to the equipment that may not be covered under the warranty.
The term “IMPORTANT!” indicates instructions or information that are vital to the successful completion of the procedure.
The term "NOTE" is used to indicate additional useful information.
The intent of the lightning flash with arrowhead symbol in a triangle is to alert the user to the presence of un-insulated "dangerous"
voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to humans.
The intent of the exclamation point within an equilateral triangle is to alert the user to the presence of important safety, and operating
and maintenance instructions in this manual.
What's in the Box
(1x)
SPA2-60
SPA2-200
SPA4-60
SPA4-100
(1x)
AC Power Cord,
US
(2x)
Rack Ear
QSC P/N
CH-001344-00
(2x)
Joining Plate
QSC P/N
CH-001345-00
(2x)
Rack-Ear Spacer
QSC P/N
CH-001386-00
(6x)
Phillips Pan Head
M4 x 7 mm
(6x)
Phillips Flathead
M3 x 6 mm
(4x)
Foam Spacer
QSC P/N
PL-001023-00
(1x)
Rack-Ear Cover Label
QSC P/N
LB-001138-00
SPA 2-channel (1x)
SPA 4-channel (2x)
Euro Plug 3.5 mm,
4 pos, grn
QSC P/N
CO-000646-00
SPA 2-channel (1x)
Euro Plug 3.5 mm,
5 pos, grn
QSC P/N
CO-000644-00
SPA 2-channel (1x)
Euro Plug 3.5 mm,
4 pos, blk
QSC P/N
CO-000645-00
SPA 4-channel (1x)
Plug 3.5 mm,
10 pos, grn
QSC P/N
CO-000647-00
SPA 4-channel (1x)
Plug 3.5 mm,
10 pos, grn
QSC P/N
CO-000648-00
(1x)
Warranty
TD-000453
(1x)
Safety Information
TD-000337
TD-000500-00-D
*TD-000500-00*
