E Series
Quick Start Guide
Input Configuration
E Series two-way loudspeakers and subwoofers are designed for externally powered operation. Pass-throughs permit connection to multiple loudspeakers. The
two-way models feature internal passive crossovers for full-range operation. To use them with subwoofers, use an active crossover and separate amplification to
split the subwoofer frequencies and the remainder of the audio spectrum.
PLD and GXD Series amplifiers have E Series voicings available in their presets and loudspeaker profiles. TouchMix digital mixers also have E Series voicings
available, for use in systems that don't have PLD or GXD Series amplifiers.
E Series E110, E112, E115, E215 Block Diagram and Input Plate
— Figure 1 —
LF
E215 only
DEEP LPF
HPF
HF
LPF
LF
NL4
Barrier
Strip
NL4
1
1
1
1
2
2
2
2
E Series E118sw, E218sw Block Diagram and Input Plate
— Figure 2 —
LF
LF
NL4
Barrier
Strip
NL4
1
1
1
1
E218sw only
2
2
2
2
TD-000525-00-E
*TD-000525-00*
