HIMALAYA WB
The HIMALAYA WB is a fixed antenna,
specially de-signed to give maximum results in the
CB channel band +10 and + 12 m.
A standard socket «SO-239» is used for the
connection of the antenna.
Art. N° AFFM316
SPECIFICATIONS
Type : 1/2 wave length (λ)
Impedance : 50 Ohm (Ω)
Frequency : 22-30 MHz
Polarization : Vertical
SWR : 1.15/1
Gain : + 8 dBi
Max. power : 2000 Watt P.E.P
Band width : 8000 kHz (800 cx)
Weight : 2 kg / 4.41 lbs
Length : 5270 mm / 207.48 inches
Whip : Fiber / graphite
www.president-electronics.com
Any under warranty ex-
pedition must be done to
our factory in Barcelona -
Spain, the only authorized
to decide about the warranty
application (an original proof of purchase
sales receipt must be included).
MADE IN EUROPE - SPAIN
DESCRIPTION
1 PL-259 protection cover
2 Fixing clamp (2)
3 1
st
antenna section
4 Rubber foam (2)
5 Lock washer (2)
6 2
nd
antenna section
7 3
rd
antenna section
WARNING : Caution
with wires, you can be
electrocuted if this anten-
na touches electric power
lines.
The 1st and 2nd antenna sections
MUST NOT be exchanged with
older models, such as HIMALAYA
and BLACK PIRATE.
