INSTALLATION INSTRUCTIONS FOR PART 99-3309B
APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 5/15/2013 INST99-3309B
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• A) Radio Trim Panel • B) Radio Brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws • E) (10) White Plastic Panel Clips
• F) Interface • G) 16-pin harness • H) 4-pin to 4-pin resistor pad • I) 22-pin to 44-pin harness
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Interface included Antenna Adapter: • 40-EU55 antenna adapter
• Panel removal tool • Phillips screwdriver
• Small flat-blade screwdriver
TOOLS REQUIRED
Chevrolet Spark 2013-up
99-3309B
A
B C
F G H I
D E
• ISO DIN head unit provision with pocket
• DDIN head unit provisions
• Interface included retains factory OnStar, Bluetooth,
and all warning chimes
• Provides a 12-volt accessory power and VSS,
parking brake, and reverse signals
• Painted Matte Black
Table of Contents
Dash Disassembly
– Chevy Spark 2013-up .......................................... 2
Kit Assembly
– ISO radio provision with pocket ............................ 3
– DDIN radio provision ............................................ 4
Axxess Interface Installation
– Installing Interface.............................................5-6
– Vehicle Customization with Optional LCD .............. 7
