Philips Sonicare HX2431 Brugsanvisning
Her er Philips Sonicare HX2431 (Tandbørste) brugervejledning. 2 sider på sprog med en vægt på 3,813,297.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
www.philips.com/Sonicare
©2021 Koninklijke Philips N.V. (KPNV).
All rights reserved. Philips and the Philips shield
are trademarks of KPNV. Sonicare and the
Sonicare logo are trademarks of Philips Oral
Healthcare, LLC and/or KPNV.
©2021 Koninklijke Philips N.V. (KPNV).
保留所有权利。 飞利浦及飞利浦盾牌标志是 KPNV
的商标。 Sonicare 和 Sonicare 徽标是 Philips Oral
Healthcare, LLC 和/或 KPNV 的商标。
©2021 Koninklijke Philips N.V. (KPNV)。
版權所有。 飛利浦及飛利浦盾牌標誌為 KPNV
的商標。 Sonicare 及 Sonicare
標誌為飛利浦口腔保健公司和/或 KPNV 的商標。
300004845094 (2021-11-16)
2100 Series
2000 Series
1
2
3
4
5
6
7
2
4
3
1
1
2
5
8
3
6
9
4
7
10
English
Introduction
Congratulations on your purchase and welcome
to Philips! To fully benet from the support
that Philips oers, register your product at
www.philips.com/welcome.
Important safety information
Read this important information carefully before you
use the appliance and save it for future reference.
READ ALL INSTRUCTIONS BEFORE USE
DANGER
-Keep the charger away from water. Do not place
or store the appliance where it can fall or be pulled
into a tub or sink.
-Do not immerse the charger in water or any other
liquid.
-After cleaning, make sure the charger is
completely dry before you connect it to the wall
socket.
WARNINGS
-This appliance can be used by children and
persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Cleaning and
user maintenance shall not be made by children
without supervision.
-Children shall not play with the appliance.
-If the appliance is damaged in any way (brush
head, toothbrush handle or charger), stop using it.
-The USB cord cannot be replaced. If the USB cord is
damaged, discard the charger.
-Always replace the charger with one of the
original type in order to avoid a hazard.
-This appliance contains no user-serviceable parts.
If the appliance is damaged, contact the Consumer
Care Center in your country (see ‚Warranty and
support‘).
-Keep the cord away from heated surfaces.
-Do not use the charger outdoors.
CAUTION
-Do not clean the brush head, handle, or charger in
the dishwasher.
-If you have had oral or gum surgery in the previous
2 months, consult your dentist before you use this
appliance.
-Consult your dentist if excessive bleeding occurs
after using this appliance or if bleeding continues
to occur after 1 week of use. Also consult your
dentist if you experience discomfort or pain when
you use this appliance.
-This Philips appliance complies with the safety
standards for electromagnetic devices. If you have
a pacemaker or other implanted device, contact
your doctor or the appliance manufacturer of the
implanted appliance prior to use.
-If you have medical concerns, consult your doctor
before you use this appliance.
-This appliance has only been designed for
cleaning teeth, gums and tongue. Do not use it
for any other purpose. Stop using the appliance
and contact your doctor if you experience any
discomfort or pain.
-This appliance is a personal care device and is not
intended for use on multiple patients in a dental
practice or institution.
-Do not use other brush heads than the brand that
came with your Philips Sonicare 2000 Series or
2100 Series: Sonicare Gentle Clean brush heads.
-Stop using a brush head with crushed or bent
bristles. Replace the brush head every 3 months or
sooner if signs of wear appear.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic elds.
Battery safety instructions
-Only use thisproduct for its intended purpose and
follow the general and battery safety instructions
as described in this user manual. Any misuse can
cause electric shock, burns, re and other hazards
or injuries.
-Charge, use and store the product at a
temperature between 0°C and 40°C.
-Always unplug the product when it is fully
charged.
-Do not burn products and their batteries and
do not expose them to direct sunlight or to high
temperatures (e.g. in hot cars or near hot stoves).
Batteries may explode if overheated.
-If the product becomes abnormally hot, gives o
an abnormal smell, changes color or if charging
takes much longer than usual, stop using and
charging the product and contact your local Philips
dealer.
-Do not place products and their batteries in
microwave ovens or on induction cookers.
-This product contains a rechargeable battery that
is non-replaceable. Do not open the product to
replace the rechargeable battery.
-When you handle batteries, make sure that your
hands, the product and the batteries are dry.
-To prevent batteries from heating up or releasing
toxic or hazardous substances, do not modify,
pierce or damage products and batteries and
do not disassemble, short-circuit, overcharge or
reverse charge batteries.
-To avoid accidental short-circuiting of batteries
after removal, do not let battery terminals come
into contact with metal objects (e.g. coins,
hairpins, rings). Do not wrap batteries in aluminum
foil. Tape battery terminals or put batteries in a
plastic bag before you discard them.
-If batteries are damaged or leaking, avoid contact
with the skin or eyes. If this occurs, immediately
rinse well with water and seek medical care.
Your Philips Sonicare (Fig. 1)
1 Travel cap
2 Brush head
3 Handle
4 Power on/o and mode button
5 Brushing modes
6 Battery indicator
7 Charger
Note: Appearance may slightly dier, depending on
the model.
Note: Power adapter not included. Only use 5V
IPX4 adapter. It is recommended to use a Philips
adapter; see the Philips website for current
information.
Getting started
Attaching the brush head
1 Align the brush head so the bristles point in the
same direction as the front of the handle.
2 Press the brush head down onto the metal shaft
until there is a small 1-2mm gap. (Fig. 3)
Note: It is normal to see a slight gap between the
brush head and the handle (Fig. 3). This allows the
brush head to vibrate properly.
Charging your Philips Sonicare
1 Place the power toothbrush handle on the charger
(Fig. 4).
2 Connect the charger to a 5V USB wall adapter.
3 Your toothbrush continues to charge until it is fully
charged.
-When the toothbrush is charging, the battery
indicator pulsates green.
-When fully charged, the battery indicator will
light up solid green for 30 seconds before
turning o.
Note: It can take up to 10 hours to fully charge the
battery, but you can use the toothbrush before it is
fully charged.
Using your Philips Sonicare
toothbrush
If you are using your Sonicare toothbrush for the
rst time, it is normal to feel more vibration than
when using a non-electric toothbrush. It is common
for rst time users to apply too much pressure. Only
apply gentle pressure and let the toothbrush do the
brushing for you. Please follow brushing instructions
below for the best experience.
Brushing instructions
1 Wet the bristles and apply a small amount of
toothpaste.
2 Place the toothbrush bristles against the teeth at
a slight angle (45 degrees) (Fig. 5), pressing gently
to make the bristles reach the gumline or slightly
beneath the gumline.
Note: Do not turn on the toothbrush until the
brush head is against your teeth.
3 Press the power on/o button to turn on the
Philips Sonicare.
Note: Keep the center of the brush in contact with
the teeth at all times.
4 Gently keep the bristles placed on the teeth and
in the gumline. Brush your teeth with small back
and forth motion so the bristles reach between
the teeth. Continue this motion throughout your
brushing cycle.
Note: The bristles should slightly are. Do not
scrub. It is not recommended to scrub as you
would with a manual toothbrush.
5 To clean the inside surfaces of the front teeth, tilt
the brush handle semi-upright and make several
vertical overlapping brushing strokes on each
tooth (Fig. 6).
Note: To make sure you brush evenly throughout
the mouth, divide your mouth into 4 sections using
the Quadpacer feature (see chapter ‘Features’).
6 Begin brushing in section 1 (outside upper teeth)
and brush for 30 seconds before you move to
section 2 (inside upper teeth). Continue brushing
in section 3 (outside lower teeth) and brush for
30 seconds before you move to section 4 (inside
lower teeth) (Fig. 7).
7 After you have completed the brushing cycle, you
can spend additional time brushing the chewing
surfaces of your teeth and areas where staining
occurs. You can also brush your tongue, with the
toothbrush turned on or o, as you prefer (Fig. 8).
Note: To switch o the power toothbrush, hold
down the power button for 3 seconds or more.
Your Philips Sonicare toothbrush should be safe to
use on braces (brush heads wear out sooner when
used on braces) and dental restorations (llings,
crowns, veneers) if they are properly adhered and not
compromised. If a problem occurs, please follow up
with a dental professional.
Battery status
This Philips Sonicare toothbrush is designed to provide
at least 60 brushing sessions after fully charged for
10 hours, each session lasting 2 minutes. When the
battery is low, the battery indicator starts to ash.
Note: When the battery is completely empty, the
toothbrush switches o. Place the handle on the
charger to charge it.
Note: To keep the battery fully charged at all times,
you may keep your Philips Sonicare toothbrush on
the charger when not in use.
Note: Battery usage time is expected to reduce
over product life time.
Features
Brushing modes
Your power toothbrush is equipped with two
dierent modes:
Clean
Complete whole mouth cleaning (2 minutes).
Sensitive
Gentle cleaning for sensitive gums and teeth
(2minutes).
Note: When you use the toothbrush for the rst
time, the default mode is ‚clean‘,
To toggle between the brushing modes:
-Press the power button once to turn on the
toothbrush
-Press a second time to change within 3 seconds
the brushing mode
-After the toothbrush has been on ve seconds,
if you want to change modes, you‘ll need to turn
the toothbrush o, then on and press the power
button within 3 seconds.
-You can also hold the power button down for
3seconds or more to turn o.
Smartimer
The Smartimer indicates that your brushing cycle is
complete by automatically turning o the toothbrush
at the end of the brushing cycle.
Dental professionals recommend brushing no less
than 2 minutes twice a day.
Quadpacer
The Quadpacer is an interval timer that has a short
pause every 30 seconds to remind you to brush the
4sections of your mouth evenly and thoroughly (Fig.7).
Cleaning
You should clean your Philips Sonicare toothbrush
regularly to remove toothpaste and other residue.
Failure to clean your Philips Sonicare toothbrush may
result in an unhygienic product and damage to it may
occur.
Warning: Do not clean brush heads, the handle
or the charger in the dishwasher.
Warning: Do not clean with boiling hot water.
Toothbrush handle
1 Remove the brush head and rinse the metal shaft
area with warm water (Fig. 9). Make sure you
remove any residual toothpaste.
Caution: Do not push on the rubber seal on the
metal shaft with sharp objects, as this may cause
damage.
2 Wipe the entire surface of the handle with a damp
cloth.
Note: Do not tap the handle on the sink to remove
excess water.
Brush head
1 Rinse the brush head and bristles after each use
(Fig. 10).
2 Remove the brush head from the handle and rinse
the brush head connection with warm water at
least once a week. Rinse the travel cap as often as
needed.
Charger
1 Unplug the charger before you clean it.
2 Wipe the surface of the charger with a damp cloth.
Storage
If you are not going to use the product for a long
time, unplug it, clean it (see chapter ‚Cleaning‘) and
store it in a cool and dry place away from direct
sunlight.
Replacement
Brush head
Replace Philips Sonicare brush heads every 3 months
to achieve optimal results. Use only Philips Sonicare
Gentle Clean brush heads compatible with Philips
Sonicare 2000 Series or 2100 Series handle.
Troubleshooting
This chapter summarizes the most common problems
you could encounter with the appliance. If you are
unable to solve the problem with the information
below, visit www.philips.com/support for a list of
frequently asked questions or contact the Consumer
Care Center in your country.
Problem Possible cause Solution
I cannot fully
attach the brush
head. There is
a gap between
the brush head
and handle.
This is normal.
A small gap
is necessary
to allow
movement in
order to deliver
the vibrations
needed to clean
your teeth.
My Philips
Sonicare
toothbrush
vibration is less
powerful than
before.
The brush head
is too close to
the body of the
handle.
Remove the
brush head
from the handle
and re-set it on
the metal shaft
leaving small
gap. (1-2mm)
I have charged
my toothbrush,
but it only
works for a
short time.
The toothbrush
handle is not
placed vertically
on the charger,
resulting in no
charge.
Place handle
vertically on
charger base
and make sure
the charger is
plugged in.
The toothbrush
stops working.
The battery is
empty.
Charge the
toothbrush
handle on the
charger.
Recycling
-Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an ocial collection point for recycling. By
doing this, you help to preserve the environment.
-This product contains a built-in rechargeable
battery which shall not be disposed of with normal
household waste. Please take your product to an
ocial collection point or a Philips service center
to have a professional remove the rechargeable
battery.
-Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product. Before you remove
the battery, make sure that the product is
disconnected from the wall socket and that the
battery is completely empty.
Take any necessary safety precautions when
you handle tools to open the product and
when you dispose of the rechargeable battery.
1 Remove the inner body from the handle.
2 Remove the rechargeable battery from the inner
body.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the international
warranty leaet.
Warranty restrictions
The terms of the international warranty do not cover
the following:
-Brush heads.
-Damage caused by use of unauthorized
replacement parts.
-Damage caused by misuse, abuse, neglect,
alterations or unauthorized repair.
-Normal wear and tear, including chips, scratches,
abrasions, discoloration or fading.
简体中文
说明
感谢您的惠顾，很高兴您选择
飞利浦！为了让您能充分享
受飞利浦提供的支持，请在
www.philips.com/welcome
上注册您的产品。
重要安全信息
使用产品之前，请仔细阅读本重要信
息，并妥善保管以供日后参考。
使用前请阅读所有说明
危险
-使充电器远离水源。 请勿将本产品
放置或保存在可能掉落或推入浴缸或
水槽的地方。
-不要将充电器浸入水中或其他液体
中。
-清洁后，务必确保充电器完全干燥，
再将其连接至电源插座。
警告
-本产品适合由儿童和肢体不健全、感
觉或精神上有障碍或缺乏相关经验和
知识的人士使用，但前提是有人对他
们使用本产品进行监督或指导，以确
保他们安全使用，并且让他们明白相
关的危害。 不要让儿童在无人监督
的情况下对本产进行清洁和保养。
-切勿让儿童玩弄本产品。
-如果本产品受到任何损坏（刷头、
牙刷手柄或充电器），请停止使用。
-不得更换 USB 线缆。 如果 USB 线缆
损坏，请丢弃充电座。
-务必使用原装型号的充电座进行更
换，以免发生危险。
-本产品不包含任何用户可维修的零
部件。 如果本产品已损坏，请联系
您所在国家/地区 (请参见 ‚保修和支
持‘)的客户服务中心。
-请将电源线远离高温表面。
-切勿在户外使用充电座。
警告
-请勿在洗碗机中清洗牙刷头、手柄或
充电座。
-如果您在前 2 个月中曾做过口腔或牙
龈手术，请在使用本产品前先咨询您
的牙医。
-如果使用本产品后牙龈大量出血或在
使用 1 周后仍会出血，请咨询您的牙
医。 如果使用本产品时感觉不适或
疼痛，也请咨询您的牙医。
-本飞利浦产品符合电磁装置的安全标
准。 有关任何涉及心脏起搏器或其
他植入装置的问题，请在使用之前咨
询医生或相关植入产品的产品制造
商。
-如果您有医学问题，请在使用本产品
前咨询您的医生。
-本产品设计仅用于清洁牙齿、牙龈
和舌头。 请勿将其用作任何其它用
途。 如果感觉任何不适或疼痛，请
停止使用本产品并与医生联系。
-本产品为私人用品，不可供牙医诊所
或机构对多位患者使用。
-切勿使用非 Philips Sonicare 2000
Series 或 2100 Series 随附品牌的其
他刷头： Sonicare 温和清洁刷头。
-请停止使用变形或刷毛弯曲的牙刷
头。 请每 3 个月更换一次牙刷头，
如果出现磨损迹象，应提前更换。
电磁场 (EMF)
本 Philips 产品符合所有有关暴露于电
磁场的适用标准和法规。
电池安全说明
-仅可将本产品用于原定用途，并应遵
循本用户手册中的一般说明和电池安
全说明。 如有滥用，可能会导致电
击、烧伤、火灾和其他危害或伤害。
-充电、使用和存放本产品的温度应介
于 0 °C 至 40 °C 之间。
-产品充满电后务必拔下电源插头。
-切勿燃烧产品及其电池，也不要将其
暴露在阳光直射或高温的环境中（例
如炎热的汽车内或热炉附近）。 如
果过热，电池可能会爆炸。
-如果产品异常发热、发出异味、变色
或充电时间比平时长，请停止使用并
停止为其充电，并联系您当地的飞利
浦经销商。
-切勿将产品及其电池放置在微波炉中
或电磁炉上。
-本产品包含不可更换的充电电池。
切勿拆开本产品更换充电电池。
-处理电池时，请确保您的双手、产品
和电池都是干燥的。
-为防止电池发热或释放有毒有害物
质，切勿改装、刺穿或损坏产品和电
池，切勿拆卸电池、使电池短路、过
度充电或反向充电。
-为避免电池拆卸后发生意外短路，
切勿让电池端子接触金属物体（例如
硬币、发夹、戒指）。 切勿用铝箔
包裹电池。 在丢弃之前，请用胶带
将电池端子粘住或将电池放在塑料袋
中。
-如果电池损坏或出现泄漏，请避免与
皮肤或眼睛接触。 如果不慎接触，
请立即用清水冲洗并就医。
Philips Sonicare（图 1）
1 旅行保护盖
2 牙刷头
3 手柄
4 电源开/关和模式按钮
5 刷牙模式
6 电量指示灯
7 充电器
注意： 外观可能略有不同，具体取决于
型号。
注意： 不随附电源适配器。 在中国，
使用者必须使用符合
GB4706.1-2005标准的5V直
流、2W、IPX4电源适配器。 建议使用
飞利浦适配器；有关最新信息，请访问
飞利浦网站。
开始使用
安装牙刷头
1 对齐牙刷头，使刷毛方向与牙刷手
柄正面的方向一致。
2 将刷头向下按到金属轴上，直至剩
余 1-2mm 的小间隙为止。 (图 3)
注意：刷头与手柄之间会有微小间隙，
这属于正常现象 (图 3)。 这样刷头才能
正常振动。
为您的飞利浦 Sonicare 声波震动牙刷
充电
1 将电动牙刷手柄置于充电器上
(图 4)。
2 将充电器连接到 5V USB 插墙式适
配器。
3 您的牙刷将持续充电，直至充满
电。
-牙刷在充电时，电池指示灯呈绿
色闪烁。
-充满电后，电池指示灯将呈绿色
持续亮起 30 秒，然后关闭。
注意： 电池充满电需要 10 小时，
不过牙刷在未充满电时亦可使用。
MONTANA-low_ 300004845094_DFU-ROW-CHINA_LEALFET_foldedA7_BW.indd 1-6
MONTANA-low_ 300004845094_DFU-ROW-CHINA_LEALFET_foldedA7_BW.indd 1-6
MONTANA-low_ 300004845094_DFU-ROW-CHINA_LEALFET_foldedA7_BW.indd 1-6
MONTANA-low_ 300004845094_DFU-ROW-CHINA_LEALFET_foldedA7_BW.indd 1-6MONTANA-low_ 300004845094_DFU-ROW-CHINA_LEALFET_foldedA7_BW.indd 1-6
22-11-21 16:35
22-11-21 16:35
22-11-21 16:35
22-11-21 16:3522-11-21 16:35
Problemløsning Philips Sonicare HX2431
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Mærke: | Philips |
| Kategori: | Tandbørste |
| Model: | Sonicare HX2431 |
