Side 1/12
Quick Guide for Installation
Video Intercom System — Lobby station/Distributor
Model No. VL-VM series / VL-VM701
Lobby station
(16 call buttons)
Lobby station
(8 call buttons)
Distributor
(VL-VM701)*1
Thank you for purchasing a Panasonic product.
Please follow all instructions in this document and save it for future reference.
Carefully read the information found in the section titled "Important safety information" of the "Important
Information" leaflet (supplied separately) in particular.
*1 In India, VL-VM701 is not sold and bus wiring is not available.
R The product is not compatible with HAC (Hearing Aid Compatibility).
This system is an auxiliary system; it is not designed to provide complete protection from property loss.
Panasonic will not be held responsible in the event that property loss occurs while this system is in operation.
Note to the installer
R Please read this document carefully, and install the product safety and correctly by following the
instructions.
R This document explains the following items.
– System configuration (star wiring and bus wiring)
– Wiring connections (star wiring and bus wiring)
– DIP switch settings (lobby station and distributor DIP switches)
How to get documentation
R For detailed information, such as lobby station components, included items, power supply unit connections,
module assembly, and lobby station connections, download and refer to the Installation and Operating
Instructions.
https://panasonic.net/cns/pcc/support/intercom/vl-vm
