Specications
Main unit
Power supply
AC 200V-240V, 8.5A, 50/60Hz
The light output will decrease to approximately 1/2 when using the projector with
AC 100V to AC 120V [9.8A].
Power consumption
1,650 W (1,690 VA [AC200V]) (0.3 W with Standby Mode set to Eco*
1
,
4 W with Standby Mode set to Normal)
1,140W (Normal Mode), 1,380 W (Eco Mode)
Operating Temperature: 25 °C (77 °F), Altitude: 700m (2,297ft),
IEC627087: 2008 Broadcast contents, Picture mode: Standard, Dynamic contrast [2]
BTU value
Max 5,364 BTU
DLP™ chip Panel size 22.9 mm (0.9 inches) diagonal (16:10 aspect ratio)
Display method DLP™ chip × 3, DLP™ projection system
Pixels 4,096,000 (2560 ×1600) ×3, total of 12,288,000 pixels
49,152,000 (12,288,000 x 4) pixels when Quad Pixel Drive set to ON
Refresh rate 240 Hz*
2
Lens Optional (no lens included with this model)
Light source Laser Diode (Laser class: Class 1)*Class 3R for North America/China.
Illumination life of set Varies depending on operation mode setting.
20,000 hours at half luminance (Normal) 24,000 hours at half luminance (Eco)
* IEC62087: 2008 Broadcast contents, Dynamic contrast [3]
(NORMAL/ECO Temperature: 30°C (86°F), Altitude 700m (2,297 ft),Dynamic
Contrast [3] Under conditions of 0.15 mg/m
3
of particulate matter
Screen size (diagonal) 1.78–25.4 m (70–1,000 in) with 16:10 aspect ratio
1.78–15.24 m (70–600 in) with the ET-D75LE8/ET-D3LET80, 16:10 aspect ratio
3.05–15.24 m (120–600 in) with the ET-D75LE95, 16:10 aspect ratio
Brightness*
4
21,000 lm (Center)*
3
*
5
/ 20,000 lm
Center-to-corner uniformity
90 %
Contrast*
4
20,000:1 (Full On/Full Off, Dynamic Contrast Mode: 3)
Resolution 5120 ×3200 pixels when Quad Pixel Drive set to ON
Scanning frequency SDI signal input SD-SDI signal
HD-SDI signal
3G-SDI signal
DIGITAL LINK signal input
• Moving image signal resolution: 480/60i*
6
, 576/50i*
6
to 4096 x 2160
Still image signal resolution: 640 x 400 to 3840 x 2400 (non-interlace)
• Dot clock frequency: 25 MHz to 297 MHz
HDMI signal input
This is supported when the optional Interface Board for HDMI 2 input (Model No.: ET-MDNHM10) is installed in the slot.
• Moving image signal resolution: 480/60i*
6
, 576/50i*
6
to 4096 x 2160
Still image signal resolution: 640 x 400 to 3840 x 2400 (non-interlace)
• Dot clock frequency: 25 MHz to 594 MHz
DVI-D signal input
This is supported when the optional Interface Board for DVI-D 2 input (Model No.: ET-MDNDV10) is installed in the slot.
• Moving image signal resolution: 480/60i*
6
, 576/50i*
6
to 2048 x 1080
Still image signal resolution: 640 x 400 to 1920 x 1200 (non-interlace)
• Dot clock frequency: 25 MHz to 162 MHz
Lens shift Vertical (from center of screen) ±59 % (±56 % with ET-D75LE6/ET-D3LEW60, +69 % – +84 %
with ET-D75LE95) (powered)
Horizontal (from center of screen)
±29 % (±19 % with ET-D75LE6/ET-D3LEW60, ±21 %
with ET-D75LE95) (powered)
NOTE: Optical axis shift function cannot be operated when used with the ET-D3LEW50.
PT-RQ22K
3-Chip DLP™ Projector
As of July 2018 1/30
RQ22KG_SYK_01_27/07/2018
Problemløsning Panasonic PT-RQ22K
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Bredde: | 598 mm |
| Dybde: | 725 mm |
| Højde: | 270 mm |
| Vægt: | 55000 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Sort |
| Produkttype: | Projektor til stort spillested |
| Naturligt aspektforhold: | 16:10 |
| Relativ luftfugtighed ved drift (H-H): | 10 - 80 % |
| HDCP: | Ja |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 2.0-porte: | 2 |
| Ethernet LAN: | Ja |
| Strømforbrug (standby): | 0.3 W |
| Strømforbrug (typisk): | 1650 W |
| Driftstemperatur (T-T): | 0 - 45 °C |
| Husmateriale: | Plast |
| Understøttede billedformater: | 16:10 |
| Støjniveau: | 46 dB |
| Strømkilde: | Vekselstrøm |
| Placering: | Desktop |
| Full HD: | Ja |
| Kontrastforhold (typisk): | 2000:1 |
| Projektor lysstyrke: | 21000 ANSI lumens |
| Projektionsteknologi: | DLP |
| Projektor indbygget opløsning: | 4K+ (5120x3200) |
| Skærmstørrelse kompatibilitet: | 70 - 1000 " |
| Ensartethed: | 90 % |
| Trapezkorrektion, vertikal: | -40 - 40 ° |
| Matrix størrelse: | 0.9 " |
| Levetid for lyskilde: | 20000 t |
| Lyskilde type: | Laser |
| Seriel grænsefladetype: | RS-232C |
| Trapezkorrektion, horisontal: | -15 - 15 ° |
| Horisontalt område for optisk linseforskydning: | -29 - 29 % |
| Vandret område for optisk linseforskydning: | -55 - 55 % |
| BNC-indgangsporte: | 6 |
| Smart projektor: | Ja |
