Valve Regulated Lead-Acid Batteries
12
97 1
+
-
+
-
47.5 1
30.
8
4.75
+
-
47
0.3
50 1
96.5
Nominal voltage 12 V
Rated capacity (20 hour rate) 1.3 Ah
Dimensions
Length 97 mm
Width 47.5 mm
Height 50 mm
Total Height 55 mm
Approx. mass 0.59 kg
Specifications
Dimensions (mm)
14.4
13.8
13.2
12.6
12.0
11.4
10.8
10.2
9.6
9.0
8.4
7.8
0 1 2 4 6 8 10 20 40 60 2 4 6 8 10 20 40
(Minute) (Hour)
Duration of dischar
g
e
Terminal voltage (V)
1.3 A
0.26 A
0.13 A
0.065 A
Discharge characteristics (20 °C)
(Note)
30
20
15
10
5
4
3
2
1.5
1
50
40
30
20
10
5
3
30 50 100 300 500 1 3 5 10
Dischar
g
e current
(mA)
(A)
(Minute) (Hour)
Duration of discharge
40˚C
20˚C
0˚
C
-15˚C
Duration of discharge vs. Discharge current
(Note)
Capacity
(note)
(20 °C)
20 hour rate (65 mA)
10 hour rate (120 mA)
5 hour rate (210 mA)
1 hour rate (850 mA)
1.30 Ah
1.20 Ah
1.05 Ah
0.85 Ah
1.5 hour rate discharge
Cut-off voltage 10.5 V
0.6 A
Internal resistance
Fully charged battery
(20 °C)
Approx. 90 mΩ
Temperature dependency
of capacity (20 hour rate)
40 °C
20 °C
0 °C
-15 °C
102 %
100 %
85 %
65 %
Self discharge
(20 °C)
Residual capacity after
standing 3 months
Residual capacity after
standing 6 months
Residual capacity after
standing 12 months
91 %
83 %
66 %
Characteristics
For main and standby power supplies.
Expected trickle life: 6 – 9 years at 20 °C, Approx.
(Note) The above characteristics data are average values obtained within
three charge/discharge cycles, not the minimum values.
LC-R121R3P
Terminal type: Faston 187
Battery case resin: Standard (UL94HB)
VdS
