INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before attempting to install, operate or service
the Panasonic product. Please carefully read the “GENERAL SAFETY INFORMATION”
Failure to comply with instructions could result in personal injury or property damage.
Please explain to users how to operate and maintain the product after installation,
and this booklet should be presented to users.
Please retain this booklet for future reference.
Representative models:
FV-0511VQL1
FV-1115VQL1
FV-0511VQCL1
Ventilating Fan
FV-1115VQL1
FV-0511VQCL1
Model No.
FV-0511VQL1
Contents
GENERAL SAFETY INFORMATION
DESCRIPTION
UNPACKING
SUPPLIED ACCESSORIES
DIMENSIONS
WIRING DIAGRAM
SELECTOR INDICATION (FV-0511VQCL1 only)
OPERATION (FV-0511VQCL1 only)
FEATURE
INSTALLATION (NEW CONSTRUCTION)
INSTALLATION (RETROFIT)
MAINTENANCE (CLEANING)
PRACTICAL GUIDE TO INSTALLATION
SPECIFICATIONS
PRODUCT SERVICE
--------------2~3
----------------------------------------4
-----------------------------------------4
--------------------------4
-----------------------------------------5
-----------------------------------6
---------6
-----------------7
---------------------------------------------7
--------8~9
-----------------------10
------------------10~11
-----------11
-----------------------
------------ 11
--------------------
BACK COVER
1 1 Q C L 1 4 2 0 B
