OWC Mercury Accelsior Brugsanvisning
Her er OWC Mercury Accelsior (Solid State-drev (ssd)) brugervejledning. 1 sider på sprog med en vægt på 942,821.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/1
TECHNICAL SUPPORT
HOURS OF OPERATION
8AM - 8PM CST Monday - Friday
9AM - 4PM CST Saturday
By Telephone - (800) 275-4576 (North America)
International customers please call (815) 338-8685
Live Chat is available Mon-Fri 8AM-8PM | Sat 9AM-4PM
Visit: http://www.macsales.com/support for more information.
Or, you can email. Submit your email at
http://eshop.macsales.com/Service/Tech.cfm
PACKAGE CONTENTS
• OWC Mercury Accelsior PCIe Card
• Two OWC Mercury Accelsior SSD blades
• Quick Start Guide
WARRANTY INFORMATION
The complete hardware warranty information for your OWC Mercury Accelsior
PCIe SSD can be found at: http://eshop.macsales.com/Service/warranty_info.cfm.
These warranties are expressly subject to the website Terms & Conditions
(“Terms”) & Terms of Sale located at http://eshop.macsales.com/service/terms/sale,
which are hereby incorporated herein and made a part hereof by this reference.
For OWC’s complete Return Policies, please visit http://eshop.macsales.com/
service/returnpolicy.
STEP 1:
Open the computer system’s chassis and locate an unused PCIe 2.0
or 1.0 slot (x8, or p1-x16 slot required). For optimal performance, use a
PCIe 2.0 slot running at p1-x8 speeds or greater.
STEP 2:
Remove the PCI slot cover.
STEP 3:
Gently insert the Mercury Accelsior card into the PCIe slot and
secure the bracket to the computer chassis according to your
chassis specifications.
STEP 4:
After installing the Mercury Accelsior card , start your computer.
STEP 5:
Insert your preferred operating system install disc and proceed
to install as usual.
Your computer is a static-sensitive device. It is susceptible
to invisible damage if not protected during installation.
We recommend proper grounding by using a grounding
strap. Make sure to work in a clean and static-free area,
and avoid wearing clothing that retains static charges.
For more information, please visit: http://www.macsales.com/static
HARDWARE INSTALLATION
Before Installing the OWC Mercury Accelsior PCIe Card & SSDs...
• Make sure computer is turned o and unplugged from its power source
• Take appropriate electrostatic discharge precautions:
SYSTEM REQUIREMENTS & INSTALLATION
MAC® REQUIREMENTS
OPERATING SYSTEM: Mac OS X 10.5 and later
HARDWARE: Intel-based Mac with an available PCIe 2.0 or 1.0 slot capable
of supporting an p1-x2 (2-lane) length PCIe card. For optimal
performance, use a PCIe 2.0 slot running at p1-x4 speeds or greater.
PC REQUIREMENTS
OPERATING SYSTEM: Windows® Vista and later
HARDWARE: Any computer with an available PCIe 2.0 or 1.0 slot capable
of supporting an p1-x2 (2-lane) length PCIe card. For optimal
performance, use a PCIe 2.0 slot running at p1-x4 speeds or greater.
QUICKSTART GUIDE
See OWC’s complete lineup
of high performance SSDs at
http://www.macsales.com/ssd
DESIGNED & BUILT IN THE USA
U
S
I
N
G
H
I
G
H
E
S
T
Q
U
A
L
I
T
Y
S
T
A
N
D
A
R
D
S
A
N
D
I
M
P
O
R
T
E
D
P
A
R
T
S
Mercury Accelsior
PCI Express SSD
™
OWCMANINSSDACC2
Problemløsning OWC Mercury Accelsior
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 20.7 mm |
| Dybde: | 180 mm |
| Højde: | 120 mm |
| Vægt: | 85 g |
| Produktfarve: | Blå |
| Opbevaringstemperatur (T-T): | -55 - 150 °C |
| Driftstemperatur (T-T): | 0 - 70 °C |
| Sikkerhedsalgoritmer: | 128-bit AES |
| Forbindelsesteknologi: | Ledningsført |
| Certificering: | RoHS |
| Læsehastighed: | 756 MB/s |
| Skrivehastighed: | 673 MB/s |
| Understøttede Windows-operativsystemer: | Ja |
| Understøttede Mac-operativsystemer: | Ja |
| Understøttede Linux-operativsystemer: | Ja |
| Grænseflade: | PCI Express |
| Intern: | Ja |
| Kompatible produkter: | Mac Pro\nXserve\nPC |
| SDD-kapacitet: | 960 GB |
| Hukommelsestype: | MLC |
| Tilfældig læsning (4KB): | 100000 IOPS |
| Tilfældig skrivning (4KB): | 100000 IOPS |
| Understøtter S.M.A.R.T.: | Ja |
| Fejlkorrigerende kode: | Ja |
| Bytes pr. sektor: | 512 |
| Ventetid ved læsning: | 0.1 µs |
| Ventetid ved skrivning: | 0.1 µs |
| Native Command Queuing (NCQ): | Ja |
