Specifications and appearances are subject to change without any notice or obligation on the part of the manufacturer
VN-711PC DNS
• Includes Dragon Naturally
Speaking Software
• USB connection for fast
downloading to PC
• 2GB internal memory / up
to 800 hours recording (LP
mode)
• Low-cut filter
• Recording Scenes • 5 folders for file storage,
200 messages per folder
• Voice activated recording
(VCVA)
• Long battery life
Speak. Record. Transfer
The new VN-PC series is absolutely ideal for anybody looking for a user-friendly voice recorder with outstanding long battery life. As
an excellent entry-level device the VN-711PC offers fine WMA recording quality and 2GB memory enabling an outstanding recording
time of more than 800 hrs in LP mode. As well as featuring probably the best low-noise microphone in its class for superior sound
reproduction, it also has a high-speed USB connection for organising and archiving recordings on a PC or Mac, or sharing them via
e-mail - and all this with great ease. And the benefits don’t stop here either. They include the low-cut filter for noise reduction while
recording, the Scene Select and Automatic Recording (VCVA) features and 99 Index Marks - all designed for maximum user-friendliness.
For those who want the convenience of having their spoken words automatically converted into text, the DNS version for the VN-711PC
DNS bundles Dragon Naturally Speaking 11 Recorder Edition speech recognition software to make things easy. Languages supported
are EN, FR, IT, DE, ES, NL.
Specifications
Storage Media
Internal / Removable Media Internal only
microSD / microSDHC card No
Internal memory 2GB
USB functionality
USB Speed USB 2.0 High Speed
USB Classes USB Storage class
Display
Display colour White
Display Size 29 x 29mm / 1.61''
Display Type Full Dot Matrix Display (108 x
84)
Font size setting Yes
Device operation
HOLD switch Yes
Power switch Yes
Recording Modes
Recording format WMA
Maximum Recording Time 823h (LP mode)
HQ 131h
SP 258h
LP 823h
Playback Modes
Playback format WMA
Sampling frequency
HQ 44.1kHz / 32kbps
SP 22kHz / 16kbps
LP 8kHz / 5kbps
Frequency response
HQ 70 - 16.000Hz
SP 70 - 8.000Hz
LP 70 - 3.000Hz
Problemløsning Olympus VN-711PC DNS
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 108 mm |
| Dybde: | 16.8 mm |
| Højde: | 39 mm |
| Vægt: | 71 g |
| Brugervejledning: | Ja |
| Produktfarve: | Sort |
| Skærmtype: | LED |
| Skærm diagonal: | 1.61 " |
| Skærmopløsning: | 108 x 84 pixel |
| FM radio: | Ingen |
| Batteriteknologi: | Nikkel-Metalhydrid (NiMH) |
| Indbyggede højttaler(e): | Ja |
| Understøttede lydformater: | MP3,WMA |
| Intern hukommelse: | 2048 MB |
| Kabler inkluderet: | USB |
| Batterier inkluderet: | Ja |
| Udgangseffekt: | 250 mW |
| Antal indbyggede højttalere: | 1 |
| Batterilevetid (maks.): | 72 t |
| Antal understøttede batterier: | 2 |
| Indbygget mikrofon: | Ja |
| Understøttede Mac-operativsystemer: | Mac OS X 10.4 Tiger,Mac OS X 10.5 Leopard,Mac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion |
| Optagelsestilstande: | High Quality (HQ),Long Play (LP),Standard Play (SP) |
| Grænseflade: | USB |
| Skærmstørrelse (HxL): | 29 x 29 mm |
| Understøttede medietyper: | Intern hukommelse |
| Kompatible batteristørrelser: | AAA |
| Maksimal optagetid: | 823 t |
| WMA bit-rater: | 5 - 320 Kbit/s |
| Talegenkendelse: | Ja |
| Højttaler, diameter: | 28 mm |
| Antal mapper meddelelser: | 5 |
| Antal meddelelser pr. mappe: | 200 |
| Afspilningstid: | 68 t |
| SP-optagetid: | 258 t |
| LP-optagetid: | 823 t |
| HQ-optagetid: | 131 t |
| SP-frekvenstid: | 70 - 8000 Hz |
| LP-frekvenstid: | 70 - 3000 Hz |
| HQ-frekvenstid: | 70 - 16000 Hz |
