Side 1/23
Read this user manual and in
particular the safety notes,
before using the product.
Keep the user manual for future
reference and include it when passing the
product on to third parties.
Esprinet S.p.A. will not in any way be held
responsible for injury or damage caused to
persons or property arising from misuse of
the product.
Warnings
Avoid listening at extreme volumes,
particularly for prolonged periods of time
when using the product.
If you use the product at an excessively high
volume, you could permanently damage your
hearing. Listen at a moderate volume.
Audio warnings, alerts and environmental
noises may sound different when wearing the
product.
Be aware of how these signals differ in terms
of their sound so that you are able to recognize
the signals in corresponding situations.
Do not use the product when driving motor
vehicles, cycling, when operating machines or
in other situations where impaired awareness
of noises in your surroundings could pose a
risk to you or others. At the same time, also
observe the legal regulations and provisions in
the country where you use the product.
To prevent malfunction or damage to the
product, avoid accidental falls, do not crush,
puncture or exercise a high level of pressure
on the product.
Keep the product away from humidity, water
or other liquids.
Do not store or expose your product to any
source of heat, direct sunlight, radiators,
stoves or other heat sources such as the
dashboard of your car in the summer.
Do not try to modify, repair or disassemble the
product.
Do not use a damaged product.
Do not under any circumstances use
aggressive cleaning agents, alcohol or other
chemical solutions for cleaning as they can
damage the housing or even impair the
functionality of the product.
Do not immerse the product in water or other
liquids.
ere are no serviceable parts inside the
product. Never open/disassemble it.
Keep the product out of reach of children.
Never allow children or persons with
disabilities to use electrical products without
supervision.
Make sure that children do not play with the
plastic wrapping.
¬ey may swallow it when playing and
suffocate.
Make sure children do not remove any small
parts from the product and play with them.
Charging
Upon first use, charge the battery to its
maximum capacity. To charge, plug the
charging cable into the magnetic charging port
of the product. When charging, a red light will
turn on on the left earphone. When the light
turns off, charging will be completed.
Pairing
e earphones, once you hold down the
button behind the left earphone for 3 seconds,
will turn on. e earphones must be connected
to the device within 5 minutes, otherwise they
will go into power saving mode. To activate
the Bluetooth function on your device, search
for “AIRTUNES”, select it once identified and
connect it. You will hear the “CONNECTED”
sound when pairing is completed.
Automatic reconnection
Once your device and earphones have been
paired once, they will automatically reconnect
when your device's Bluetooth is turned on and
in range.
Operations
- Power on: Press and hold the button behind
the left earphone for 2 seconds.
- Power off: Press and hold the button behind
the left earphone for 5 seconds.
- Answer/Hang up calls: Tap the left earbud
once.
- Reject a call: long press for 2 seconds
- Play/Pause Music: Tap once on the left
earphone
- Previous song: Triple Click on the left
earphone
- Next song: Double Click on the left earphone
- Volume increase: swipe up on the left
earphone
- Volume down: Swipe down on the left earcup
- Voice Assistant: Single click + a long press on
the left earphone for 3 seconds.
Automatic shutdown
1. If connected to a device, after cutting off
the Bluetooth connection, the headset will
automatically turn off after 5 minutes.
2. If you do not connect your phone, the
headset will automatically turn off after 5
minutes.
Maintenance
1. Do not use abrasive solvents to clean the
product.
2. Do not dent the product with any type of
sharp object as it may scratch or damage the
product.
3. Keep the product away from high
temperatures, dust and moisture.
Characteristics
Bluetooth Version: 5.3
Input: DC 5V/1A
Earphone charging time: 2h
Battery: Polymer physical battery,
3.7V/100mAh (0.37Wh)
Microphone sensitivity: 100±3dB
Frequency response: 20Hz - 20KHz
Rated Power: 0.88W
Maximum power: 1.2W
Operating range: 10m
Talk Time: 10h
Music Time: 12h
Usage temperature: 0 – 40°
Weight: 19.4g
Maximum radiated power: <20mW
Frequency: 2.402 - 2.480 GHz
Package contents: Earphones, user manual
and USB-C cable
CUSTOMER’S INFORMATION FOR
RIGHT WASTE OF THIS PRODUCT
(Directive 2013/56/EU)
is marking on the product or its packaging
means that the product at the end of its life,
inlcuding the unremovable battery, must
be separated from other types of waste to
recycle it responsibly.
Safely’s use of this product is guaranteed from
the respect of this instructions manual, keep it
and carefully use it for all life of the product.
e product doesn’t need any kind of technical
maintenance, NEVER DISASSEMBLE IT.
e battery inside the product is integrated
and not replaceable. Don not try to remove
li-ion/polymer battery included in inside the
product because can produce overheat’s
danger, burning and injury. e battery must
be removed only by qualified professional
techincians, that are able to remove it without
any kind of danger and to recycle it in the
respect of the law. Users should give free end
of life product into the local separate collection
centers or to the retailer, in reason of one to
one, or free if the product size is bigger than
25 cm. Adequated waste disposal permit to
award the product to recycling, treatment
with ecofriendy compatible disposal conduce
to prevent possible harm to the environment
or human health and promote the reuse and/
or product materials recycling. Unauthorized
waste disposal of electronic product, cell and
battery from houseold user involve currency
legislation sanctions.
is product complies with the
RoHS directive 2011/65/EU –
2015/863/EU. e Product has
the CE mark and therefore complies with
the safety standards established by the
European Union. Hereby, Esprinet SpA
declares that the product is in compliance
with Directive 2014/53/EU and 2015/863/
EU. e full text of the EU declaration of
conformity is available at the following
internet address: https://xchange.esprinet.
com/comp/nilox/airtunes.pdf
e power supplied by the battery charger
must be the 5 watts required by the radio
equipment, to reach the maximum charging
speed.
Nilox® is a trademark owned by Esprinet
S.p.A.
All brands are registered trademarks of their
respective owners.
Esprinet S.p.A., via Energy Park 20,
20871 Vimercate (MB) - Italy
Made in China.
www.nilox.com
for info and contacts write to contact@
esprinet.com
Instruction manual
Sports Earphones
MODEL: AIRTUNES
Rev00 - 26.02.2024
EN
