Side 1/2
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
NETGEAR INTERNATIONAL LTD
Floor 1, Building 3,
University Technology Centre
Curraheen Road, Cork,
T12EF21, Ireland
Installation Guide
16-Port Gigabit Ethernet Unmanaged
High-power PoE+ Switch, Model GS516PP
24-Port Gigabit Ethernet Unmanaged
High-power PoE+ Switch, Model GS524PP
Package contents
• SwitchmodelGS516PPorGS524PP
• Powercord(variesbyregion)
• Rack-mountkit
• Fourrubberfeet
• InstallationguideandInsightyer
Note: WerecommendthatyouuseaCategory5e(Cat5e)cableorhigher-rated
cableforGigabitEthernetconnections.
1. Register with the NETGEAR Insight app
1. SearchforNETGEAR Insightanddownloadthelatestapp.
2. SetupaNETGEARaccountifyoudonothaveone.
3. Tapthemenuintheupper-leftcorner.
4. TapREGISTER ANY NETGEAR DEVICE.
5. Entertheserialnumberlocatedonthebottomoftheswitch,orusethe
cameraonyourmobiledevicetoscantheserialnumberbarcode.
6. Tap .GO
Theswitchisregisteredandaddedtoyouraccount.Youcannowviewthe
switchintheNETGEARInsightapp.
Note: Becausethisisanunmanagedswitch,youcannotcongureormanageit
inNETGEARInsight.
2. Connect the switch
PoE+accesspoints Internet
GS516PPswitch
Sample connections
PoE+VoIPconferencephones
Router
ModelGS516PPprovidesPoE+(802.3at)poweronall16GigabitEthernetports,
withupto30Wtoeachport.ThetotalPoEpowerbudgetfortheswitchis260W
acrossallactivePoEports.
ModelGS524PPprovidesPoE+(802.3at)poweronall24GigabitEthernetports,
withupto30Wtoeachport.ThetotalPoEpowerbudgetfortheswitchis300W
acrossallactivePoEports.
3. Check the LEDs
Whenyouconnectthepowercordtotheswitchandplugitintoanelectrical
outlet,theLEDsindicatethestatus.
LED Description
Power
Solid green.Theswitchispoweredonandoperatingnormally.
Off. Powerisnotsuppliedtotheswitch.
Fan
Off.Thefanisworkingcorrectly.
Solid yellow.Thefanisnotworkingcorrectly.
PoEMax
(Thestatusof
theswitch’s
PoEbudget)
Off.Sufcient(morethan7Wof)PoEpowerisavailable.
Solid yellow.Lessthan7WofPoEpowerisavailable.
Blinking yellow.Atleastonceduringtheprevioustwominutes,
lessthan7WofPoEpowerwasavailable.
LeftportLED 


Solid green.1000Mbpslinkonthisport.
Blinking green.1000Mbpsactivityonthisport.
Solid yellow.100Mbpsor10Mbpslinkonthisport.
Blinking yellow.100Mbpsor10Mbpsactivityonthisport.
Off.Nolinkisdetectedonthisport.
RightPortLED
Solid Green.TheportisdeliveringPoEpower..
Off.TheportisnotdeliveringPoEpower.
Solid yellow.APoEfaultoccurred.
Computer
Internet
non-PoE
Note:Thisswitchisdesignedforindooruseonly.Ifyouwanttoconnecttoadevice
locatedoutdoors,theoutdoordevicemustbeproperlygroundedandsurgeprotected,
andyoumustinstallanEthernetsurgeprotectorinlinebetweentheswitchandthe
outdoordevice.Failuretodosocandamagetheswitch.
WARNING: Beforeconnectingthisswitchtooutdoorcablesordevices,see
https://kb.netgear.com/000057103forsafetyandwarrantyinformation.
PoE+zoomcamera
PoE+
PoE+IPcamera

Problemløsning Netgear GS524PP

Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp

Specifikationer

Bredde: 390 mm
Dybde: 220 mm
Højde: 43 mm
Vægt: 2890 g
Produktfarve: Grå
Husmateriale: Metal
Netværksstandarder: IEEE 802.1p, IEEE 802.3at, IEEE 802.3az
LED-indikatorer: Activity, Speed
Harmoniseret systemkode (HS): 85176990
Strøm over Ethernet (PoE): Ja
Switch-type: Ikke administreret
Total Power over Ethernet (PoE): 300 W
Power over Ethernet plus (PoE+) porte, antal: 24
Power over Ethernet (PoE) effekt pr. port: 30 W
10G understøttelse: Ingen
Auto MDI/MDI-X: Ja
Basis omskiftning RJ-45 Ethernet porte, antal: 24
Basis omskiftning RJ-45 Ethernet porttype: Gigabit Ethernet (10/100/1000)
MAC adresselabel: - entries
Switch kapacitet: - Gbit/sek.
Stativ-montering: Ja
Strømforsyning inkluderet: Ja
Power over Ethernet (PoE) -type understøttet: PoE+
