Side 1/20
a Quick start guide
Window vacuum
cleaner
VCWI210WT
VCWI220WT
For more information see
the extended manual online:
ned.is/vcwi210wt ned.is/vcwi220wt|
Intended use
This product is intended to clean smooth surfaces,
such as windows, mirrors or tiles.
The window vacuum cleaner sucks up the dirty
detergent and collects it in a water tank.
The water tank of the VCWI220WT is removable for
easy emtying.
Only use this product with conventional window
cleaner.
The product is not intended for professional use.
Any modication of the product may have
consequences for safety, warranty and proper
functioning.
Main parts (image A)
1 Vacuum cleaner
2 Power button
3 Water outlet
4 Water tank
5 Power port
6 Microber wiper
7 Spray nozzle
8 Detergent bottle
9 Power cable
Safety instructions
-
WARNING
• Only use the product as described in this
manual.
• Only use the provided power supply.
• Do not repair the product. If damaged, it must
be properly disposed of.
• Check if the voltage is consistent with the
product before charging.
• Only charge the product if the plug is
compatible with the power outlet. Do not use
adapters. Do not change the plug.
• Do not use the product if a part is damaged or
defective. Replace a damaged or defective
device immediately.
• This product can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the product in a safe way and understand
the hazards involved. Children shall not play
with the product. Cleaning and user
maintenance shall not be done by children
without supervision.
• Do not expose the product to water or
moisture.
• Never immerse the product in water or place it
in a dishwasher.
• Do not unplug the charger by pulling on the
cable. Always grasp the plug and pull.
• Do not plug or unplug the charger with wet
hands.
• Do not use the product while it is being
charged.
• Do not put any objects into openings. Do not
use with any opening blocked. Keep free of
dust, lint hair etc.
• Keep hair, loose clothing, ngers and all body
parts away from openings and moving parts.
• Do not vacuum hard or sharp objects such as
glass nails, screws, coins etc.
• Do not vacuum hot coals, cigarettes, matches
or any hot smoking or burning objects.
• Do not vacuum ammable or combustible
materials (lighter uid, gasoline, etc.) or use in
the presence of explosive liquids or vapor.
• Do not use in an enclosed space lled with
vapors given o by oil-based paints, paint
thinner, moth proong, ammable dust, or
other explosive or toxic vapors.
• Store your appliance indoor in a cool, dry area.
• Keep the openings away from your face and
body.
• Do not use the cleaner to clean your pets or any
animal.
• Do not vacuum toxic material (chlorine bleach,
ammonia, drain cleaner, etc.)
• Keep the head (eyes, ear, mouth, etc.) away
from the openings, when the cleaner is working
or plugging.
• Do not open the product. There are no user
serviceable parts inside.
• Do not dry the parts using a hot air blower such
as a dryer or hair dryer.
• Do not drop the product and avoid bumping.
• This product may only be serviced by a
qualied technician for maintenance to reduce
the risk of electric shock.
• Disconnect the product from the power outlet
and other equipment if problems occur.
• For battery safety, consult the manual of the
batteries.
• Keep cells and batteries clean and dry.
• Do not subject cells or batteries to mechanical
shock.
• In the event of a battery leaking, do not allow
the liquid to come in contact with the skin or
eyes. If contact has been made, wash the
aected area with copious amounts of water
and seek medical advice.
• Seek medical advice immediately if a cell or a
battery has been swallowed.
• Do not install the battery in reverse polarity.
• Do not short circuit.
• Do not use any battery which is not designed
for use with the equipment.
• Wipe the cell or battery terminals with a clean
dry cloth if they become dirty.
• Do not dismantle, open or shred batteries.
• Do not use this product on surfaces that easily
scratch, such as wood or steel. This can damage
the rubber lips.
• The product can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the product in a safe way and understand
the hazards involved.
Installation
Prepare the product for use:
1. Charge the product for 3 hours before rst use.
2. Attach the microber wiper A6 to the
detergent bottle A8 as shown in image B.
Using the product
1. Unplug the product.
2. Fill A8.
4Only use conventional window cleaners.
Using spirit or foam concentrates leads to leakage
from the air vents.
3. Spray the detergent evenly onto the window.
4. Wipe the window with A6 to loosen the dirt.
5. Press the power button A
3 to switch on the
product.
6. Wipe the window from top to bottom with the
product to suck up the dirty detergent.
7. Press A3 to switch o the product.
Empty the water tank A4
When the water in A reaches the 70 ml / 200 ml 4
mark, empty A4.
4For VCWI220WT: A4 is removable for easy
emptying.
Specications
Product Window
vacuum
cleaner
Window
vacuum
cleaner
Article number VCWI210WT VCWI220WT
Input voltage 220-240V AC 220-240V AC
Main voltage 3.7 V 3.7 V
Maximum power 10 W 20 W
Suction power
maximum
1600 Pa / 10
mmHg
1600 Pa / 15
mmHg
Operating time (max) 30 minutes 30 minutes
Charging time 3 hours 3 hours
Problemløsning Nedis VCWI220WT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Kode for international beskyttelse (IP): | IPX4 |
| Vekselstrømsindgangsspænding: | 220 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50/60 Hz |
| Bredde: | 280 mm |
| Dybde: | 130 mm |
| Højde: | 340 mm |
| Vægt: | 765 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Black,White |
| Opladningstid: | 3 t |
| Batterispænding: | 3.7 V |
| Batterikapacitet: | 2.2 At |
| Ledningslængde: | 1.2 m |
| Pakkevægt: | 1210 g |
| Pakkedybde: | 110 mm |
| Pakkebredde: | 330 mm |
| Pakkehøjde: | 225 mm |
| Batteriteknologi: | Lithium |
| Årligt energiforbrug: | - kWh |
| Husmateriale: | Plast |
| Indikatorlampe: | Ja |
| Strømkilde: | Batteri |
| Maksimal indgangseffekt: | 20 W |
| Støvbeholder type: | Poseløs |
| Støvkapacitet: | - L |
| Rengøringstype: | Våd |
| Rengøring af overflader: | Mirror,Tile,Window |
| Kapacitet, beskidt, tørt: | - L |
| Kørselstid: | 30 min. |
| Sugekraft: | 2000 Pa |
| Vakuumvæg montering: | Ingen |
| Strømstiktype: | Type C |
| Driftstid: | 30 min. |
| Væsketank, kapacitet: | 0.2 L |
| Beholderen er nem at tømme: | Ja |
| Beholder, materiale: | Plast |
