CATV Amplifier
for connection of two receivers (TV/Radio)
SAMP42221WT
• For distributing TV, FM & DAB signal
• For up to 2 TVs
• Gain adjust 7-25dB
• Self switch power supply
• IEC type connectors
Features:
Traditional mains-powered multi-way aerial ampli ers, for o-air VHF and UHF signal distribution.
The range includes a one-way unit which can be used as a signal booster or line-extender amplier
2-Way 'active splitter' products.
Single-input, with wideband frequency coverage
Technical Information:
Ltem Unit Specication
Frequency Range MHZ 47-862
Gain dB 25±2
Gain Adjustment dB 4-20
Output Level dBuV 103
Noise Figure dB <4
Return Loss dB >8
Impedance Ω 75
Main Voltage V 230±10%,50/60Hz,50VA
Connector IEC type Female and Male connector
Disposal
The product is designated for separate collection at an appropriate collection point.
Do not dispose of the product with household waste. For more information, contact the retailer
or the local authority responsible for the waste management.
Nedis BV
De Tweeling 28, 5215 MC ’s-Hertogenbosch – The Netherlands
