Side 1/18
a Quick start guide
FM Audio Transmitter CATR101BK
For more information see the extended manual
online: ned.is/catr101bk
Intended use
The product is exclusively intended for use in a vehicle with an
auxiliary power outlet.
The product is exclusively intended for streaming audio to a car's
FM radio, answering mobile phone calls via Bluetooth and charging
devices via USB.
Any modication of the product may have consequences for safety,
warranty and proper functioning.
Parts list [Image A]
1 MicroSD card slot 7 Frequency up
2 Display 8 Play / Pause or Answer / Hang up
3 Previous song / Volume down 9 Frequency down
4 Bass Booster q USB port (2.4 A)
5 Next song / Volume up w USB port (3.0 A)
6 AUX port e Auxiliary power plug
Safety instructions
-
WARNING
• Only use the product as described in this manual.
• Do not use a damaged product.
• Do not expose the product to water or moisture.
• Do not drop the product and avoid bumping.
Installation [image B]
To prepare the product for wireless use:
1. Plug the product in an auxiliary power outlet.
4If the car battery voltage is lower than 12 V, the display will ash.
The product can still work well, but the car may have trouble
starting the engine at a voltage lower than 11.8 V. The product
will not function at a voltage lower than 8 V.
2. Tune your car radio to an unused FM frequency.
3. Use the frequency buttons (7 & 9) to tune the product to the
same frequency as your car radio.
To prepare the product for wired use:
1. Plug the product in an auxiliary power outlet.
2. Plug the provided audio cable into the product's AUX port (6).
3. Plug the other end of the cable into the AUX port of the radio.
To connect your mobile phone to the product:
1. Activate Bluetooth on your phone and connect with the product
(CATR101BK).
2. If asked, enter the pairing code '0000'.
Play music [image C]
To stream music from the product to the FM radio, choose one of
the following options:
• Insert a Micro SD card (1). The music on the card will play
automatically.
• Play music directly from the mobile device that is connected to
the product via Bluetooth.
4Press and hold
4 for 2 seconds to switch between SD card
mode and Bluetooth mode.
To control music that is playing:
• Press 8 to play or pause the music
• Press 3 and 5 to switch between songs.
• Press 4 to activate the Bass Booster.
Answer phone calls
4When a call comes in while playing music, the product will
automatically switch to telephone mode.
• To answer an incoming call, press 8.
• To reject an incoming call, press and hold 8 for 2 seconds.
• During a call, press and hold 8 for 3 seconds to switch to private
mode.
• To call the previous number, press
8 twice.
4When making a call, you must dial the number on your phone.
Once the call connects, you can use the product's hands-free
function.
• Press and hold 8 for 2 to 3 seconds to activate the voice
assistant on your mobile phone (Siri or Google Assistant).
Charge a mobile device
To charge your device:
1. Plug the product in an auxiliary power outlet.
2. Connect your device to q or w. Use an USB cable.
Specications
Product FM Audio Transmitter
Article number CATR101BK
Input voltage 12 - 24 V
Charger output 2.4 5 V / 2.4 A
Charger output 3.0 3.6-6 V / 3.0 A
6-9 V / 2.0 A
9-12 V / 1.5 A
Wireless technologies Bluetooth® 5.0
FM
FM frequency range 87.6 - 107.9 MHz
Max. radio transmit power 4 dBm
Bluetooth frequency range 2400 - 2483.5 MHz
Bluetooth proles A2DP
HFP
Max. supported MicroSD card
capacity
32 GB
Music formats MP3
WMA
FLAC
Display 2" LED
AUX port 3.5 mm
Bass Booster Yes
Voice assistant Yes
Hands-free calling Yes
Declaration of Conformity
We, Nedis B.V. declare as manufacturer that the product from our
brand Nedis®, produced in China, has been tested according to all
relevant CE standards and regulations and that all tests have been
passed successfully. This includes, but is not limited to the RED
2014/53/EU regulation.
The complete Declaration of Conformity (and the safety datasheet
if applicable) can be found and downloaded via webshop.nedis.
com/#support
For additional information regarding the compliance, contact the
customer service:
Web: www.nedis.com
E-mail: service@nedis.com
Phone: +31 (0)73-5991055 (during oce hours)
Nedis B.V., de Tweeling 28
5215 MC ’s-Hertogenbosch, the Netherlands
Problemløsning Nedis CATR101BK
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 42 mm |
| Dybde: | 180 mm |
| Højde: | 86.6 mm |
| Vægt: | 85.7 g |
| Produktfarve: | Black,Grey |
| Indbygget skærm: | Ja |
| Skærm diagonal: | 2 " |
| Bluetooth: | Ja |
| Tuner type: | Digital |
| Antal USB 2.0-porte: | 2 |
| Understøttede lydformater: | FLAC,MP3,WAV |
| Skærm: | LED |
| Kabler inkluderet: | Lyd (3,5 mm) |
| Materiale: | ABS |
| Integreret ur: | Ingen |
| Frekvensområde: | 20 - 20000 Hz |
| Strømkilde type: | Cigartænder |
| Udgangsspænding: | 5, 6, 9, 12, 3,6 V |
| Indbygget kortlæser: | Ingen |
| Fjernbetjent: | Ja |
| Enhedsgrænseflade: | Cigartænder |
| Understøttede radiobånd: | FM |
| MP3-afspilning: | Ja |
| Mikrofonindgang: | Ja |
| DC indgangsspænding: | 12 - 24 V |
| Tilslutning af hovedtelefoner: | 3.5mm / Bluetooth |
| USB-stik type: | USB Type-A |
| Signal/støjforhold: | 65 dB |
| FM båndbredde: | 87.6 - 107.9 Mhz |
| Port 1 udgangsstrøm: | 2.4 A |
| Port 2 udgangsstrøm: | 3 A |
| Apple docking: | Ingen |
| Senderfrekvens: | 2.4 GHz |
