For answers to your Monogram,
®
Profile Series
or GE appliance questions, visit our website at
geappliances.com or call GE Answer Center
®
service, 800.626.2000.
Specification Created 2/15
Listed by
Underwriters
Laboratories
Dimensions and Installation Information (in inches)
ZSA1201JSS/ZSA1202JSS
GE Monogram
®
120 Above-the-Cooktop Advantium
®
Oven
66" MIN.
Mounting
height
from floor
30" MIN.
width required
Exhaust outlet
connects to
3-1/4" X 10" duct
16-3/8 max
(Rear)
16 max
25-1/2
16 max
30 max
Minimum distance from
door hinge side adjacentto
wall should equal 1/2-inch.
13"
MAX.
12"
MIN.
(without
obstruction)
100˚
Door open
Cabinet ontFr
SIDE VIEW A-A
Cabinet Bo om Shelftt
Filler Block
Self-Aligning Screw
Oven Top
Equivalent
to Depth of
Cabinet cessRe
This distance can
NOT eed 2” exc to
ensu properre
installation with
the pr idedov
screws.
240V and 12
0V outlets
need be spaced onto
the side if the desire is
to to setup with p
exhaust.
A
A
Note: Outside venting is optional. Vent (duct) can be horizontal or vertical.
Installation Information: This information is not
intended to be used for installing unit described.
Before installing, consult installation instructions
packed with product/kit for current dimensional data.
IMPORTANT: PLEASE READ CAREFULLY. FOR PERSONAL
SAFETY, THIS APPLIANCE BE PROPERLY GROUNDED MUST
TO AVOID SEVERE OR FATAL SHOCK.
DO NOT, UNDER ANY
CIRCUMSTANCES, CUT, DEFORM,
OR REMOVE ANY OF THE PRONGS
FROM THE POWER CORD. DO NOT
USE WITH AN EXTENSION CORD.
NEMA 14-30R Wall Receptacle
Insure proper ground
exists before use.
