Mikrotik R11E-LTE6 Brugsanvisning
Her er Mikrotik R11E-LTE6 (Netværkskort/adapter) brugervejledning. 3 sider på sprog Engelsk med en vægt på 0.5 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/3
R11e series
R11e series
R11e series
R11e seriesR11e series
R11e-LTE-US is a Cat-4 modem. It can be integrated into any MikroTikproduct that has a miniPCI-e slot.
R11e-LTE-US
R11e-LTE
R11e-4G
R11e-LTE6
Specifications
Interface – Mini-PCIe;
Temperature Operating-30°C .. +70°C
LTE Channel Bandwidth:1.4/3/5/10/15/20 MHz
LTE Category:4 (150Mbps Downlink, 50Mbps Uplink)
3G Category: R7 (Cat14 - 21.1Mbps Downlink)
LTE (FDD) bands:2/4/5/12 (1900/1700/850/700)
3G bands:2/5 (1900/850)
Installing the module in your device
R11e-TE-US for professional use. Each of the cards comes in ESD protective packaging. When handling electrical equipment please observe the following
safety precautions:
Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage;
After unpacking please place the card on the anti-static mat;
When installing make sure there are no objects that can damage or touch the PCB plate;
The card can be installed in your desired device using the factory provided screw holes in a PCB plate;
Locate miniPCIe slot on your device;
Unscrew two factory attached screws;
Optionally you can use the thermal pad by placing it under the card, the thermal pad is not included in the package;
Install the module to the miniPCIe slot and secure it with previously removed screws. Tightening torque 0,3 Nm;
Problemløsning Mikrotik R11E-LTE6
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 30 mm |
| Dybde: | 5 mm |
| Højde: | 51 mm |
| Produktfarve: | Green, Stainless steel |
| Generering af mobilnetværk: | 3G, 4G |
| Strømforbrug (typisk): | 5 W |
| Driftstemperatur (T-T): | -30 - 70 °C |
| Forbindelsesteknologi: | Ledningsført |
| Understøttede netværksprotokoller: | IPv4, IPv6 |
| Harmoniseret systemkode (HS): | 85176990 |
| Kompatible operativsystemer: | RouterOS |
| Værtsgrænseflade: | Mini PCI Express |
| Grænseflade: | WWAN |
| Intern: | Ja |
| Maksimal dataoverførselshastighed: | 300 Mbit/s |
| 4G standard: | LTE-TDD & LTE-FDD |
| Understøttelse af 3G-bånd: | 850,900,1900,2100 Mhz |
| Understøttelse af 4G-bånd: | 700,800,850,900,1800,1900,2100,2600 Mhz |
| Komponent til: | PC |
| Antennestik type: | U.FL |
