Side 1/20
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick GuideEN - English -Quick Guide:
This Quick Guide covers the model: CRS326-24S+2Q+RM.
This is Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full up to date user manual. Or scan the QR code with your mobile phone.
https://mt.lv/um
Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products athttps://mikrotik.com/products
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants
First steps:
First steps:
First steps:
First steps:First steps:
Connect with your computer to the device;
Connect the device to a power source;
Download the configuration tool ;
https://mt.lv/winbox
Start configuration within the chosen tool, using the default IP address 192.168.88.1. If the IP address is unavailable, use Winbox and choose the "Neighbors"
tab to find the device;
Proceed to connect using the MAC address. The username is "admin," and there is no password (or, for some models, check user and wireless passwords on
the sticker);
For a manual update, visit the products page at to find your product. The required packages are accessible under the
https://mikrotik.com/products
"Support&Downloads" menu;
Upload downloaded packages to the Winbox "Files" menu and reboot the device;
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
Set up your router password.
This device needs to be upgraded to RouterOS v7.10 or the latest version to ensure compliance with local authority regulations!
It is the end users responsibility to follow local country regulations. All MikroTik devices must be professionally installed
Problemløsning Mikrotik CRS326-24S+2Q+RM
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Bredde: | 443 mm |
| Dybde: | 183 mm |
| Højde: | 44 mm |
| Produktfarve: | Hvid |
| Formfaktor: | 1U |
| Antal USB 2.0-porte: | 1 |
| Driftstemperatur (T-T): | -20 - 60 °C |
| Intern hukommelse: | 64 MB |
| Kabler inkluderet: | Vekselstrøm |
| Strømforbrug (maks.): | 69 W |
| Knap til nulstilling: | Ja |
| LED-indikatorer: | Ja |
| Harmoniseret systemkode (HS): | 85176990 |
| Processorfrekvens: | 650 MHz |
| Flashhukommelse: | 16 MB |
| Strøm over Ethernet (PoE): | Ingen |
| Hukommelsestype: | RAM |
| Indbygget processer: | Ja |
| Switch-type: | Administreret |
| Switch lag: | L3 |
| 10G understøttelse: | Ja |
| Port til konsol: | RJ-45 |
| MAC adresselabel: | - entries |
| Switch kapacitet: | 640 Gbit/sek. |
| Gennnemløb: | 320 Mpps |
| Stativ-montering: | Ja |
| Strømstik: | AC-in jack |
| Hastighed for videresendelse: | 252 Mpps |
| Rack monteringskit: | Ja |
| Redundant strømforsyning: | Ja |
| Antal SFP + modulslots: | 24 |
| Antal QSFP + modulpladser: | 2 |
