Side 1/20
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick GuideEN - English -Quick Guide:
This Quick Guide covers the model:CCR2004-16G-2S+.
This is a network device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.
https://mt.lv/um
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants
First steps:
First steps:
First steps:
First steps:First steps:
Connect your PC to the MGMT/BOOT port;
Connect the device to a power source;
Configure the IP settings of your network card to 192.168.88.2/24;
Configuration should be made using Webfig in a web browser or the WinBox configuration tool ;
https://mt.lv/winbox
Open in a web browser to start setup. If the IP address is unavailable, use Winbox and choose the "Neighbors" tab to find the device. http://192.168.88.1
Proceed to connect using the MAC address. The username is "admin", and there is no password (or, for some models, check user and wireless passwords on
the sticker);
For a manual update, visit the products page at to find your product. The required packages are accessible under the https://mikrotik.com/products
"Support&Downloads" menu;
Upload downloaded packages to the Webfig or Winbox "Files" menu and reboot the device;
By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;
Set up your router password.
Safety Information:
Safety Information:
Safety Information:
Safety Information:Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
Electric shock hazard. This equipment is to be serviced by trained personnel only
Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.
This device needs to be upgraded to RouterOS v7.10 or the latest version to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations. All MikroTik devices must be professionally installed
Problemløsning Mikrotik CCR2004-16G-2S+
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Bredde: | 443 mm |
| Dybde: | 44 mm |
| Højde: | 210 mm |
| Produktfarve: | Hvid |
| Ethernet LAN-porte (RJ-45): | 16 |
| Strømforbrug (typisk): | 48 W |
| Driftstemperatur (T-T): | -20 - 60 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Intern hukommelse: | 4096 MB |
| Certificering: | CE, EAC, ROHS |
| Ethernet WAN: | Ja |
| DSL WAN: | Ingen |
| SIM-kort slot: | Ingen |
| 3G/4G kompatibilitet USB-modem: | Ingen |
| Kabelteknologi: | 10/100/1000Base-T(X) |
| Strømkilde type: | Vekselstrøm |
| Harmoniseret systemkode (HS): | 85176990 |
| Bæredygtighedscertifikater: | RoHS |
| Processorfrekvens: | 1700 MHz |
| Intern hukommelsestype: | DDR4 |
| Processorproducent: | Annapurna Labs |
| Indgangsstrøm: | 0.9 A |
| Flashhukommelse: | 128 MB |
| Fuld duplex: | Ja |
| Ethernet-grænsefladetype: | Gigabit Ethernet |
| Gennemsnitstid mellem fejl (MTBF): | 200000 t |
| Indbygget processer: | Ja |
| Stativ-montering: | Ja |
| Antal SFP modulslots: | 2 |
| Rackkapacitet: | 1U |
| Spændingsovervågning: | Ja |
| Temperaturovervågning: | Ja |
