INSTALLATION INSTRUCTIONS FOR PART RFASWC
METRA. The World’s best kits.™ metraonline.com1-800-221-0932
© COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
REV. 7/8/2014 INSTRFASWC
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
• Designedtobecompatiblewithmostmajorradiobrands
• Autodetectsradiobeingconnected,andpresetscontrols
• Abilitytodualassignsteeringwheelcontrolbuttons
• Retainssettingsevenafterthebatteryhasbeendisconnected
FEATURES
•Cuttingtool•Crimpingtool•Tape•Connectors
(example:butt-connectors,bellcaps,etc.)
TOOLS REQUIRED
Wireless SWC universal add-on
RFASWC
•A)RFASWCTransmitter•B)RFASWCinterface•C)Keypad•D)Trimring•E)RFASWCharness
•F)Female3.5mmconnectorwithBrownandBrown/Whitewires•G)12k-ohmResistor(notshown)
INTERFACE COMPONENTS
A B C D
E F
US.PAT.NOS.8014920and8214105
