Introduction
The BACKUPCAM-2 is designed to retain factory back up cameras
to be viewed through the aftermarket radio.
Note: For use in 44-way connector vehicles that have OEM
installed backup camera.
BACKUPCAM-2
Cadillac/Chevrolet/GMC 2012-up
CADILLAC
Escalade
(with NAV) 2012-up
CHEVROLET
Avalanche
(with NAV) 2012-up
Camaro
(with screen) 2013-up
Cheyenne
(with NAV) 2012-up
Equinox
(with screen) 2012-up
Silverado
(with NAV) 2012-up
Suburban
(with NAV) 2012-up
Tahoe
(with NAV) 2012-up
GMC
Sierra
(with NAV) 2012-up
Yukon
(with NAV) 2012-up
APPLICATIONS
Introduction
The BACKUPCAM-2 is designed to retain factory back up cameras
to be viewed through the aftermarket radio.
Note: For use in 44-way connector vehicles that have OEM
installed backup camera.
BACKUPCAM-2
Cadillac/Chevrolet/GMC 2012-up
CADILLAC
Escalade
(with NAV) 2012-up
CHEVROLET
Avalanche
(with NAV) 2012-up
Camaro
(with screen) 2013-up
Cheyenne
(with NAV) 2012-up
Equinox
(with screen) 2012-up
Silverado
(with NAV) 2012-up
Suburban
(with NAV) 2012-up
Tahoe
(with NAV) 2012-up
GMC
Sierra
(with NAV) 2012-up
Yukon
(with NAV) 2012-up
APPLICATIONS
INTERFACE COMPONENTS
• 16-pin GMLAN29 backup camera harness.
INSTALLATION INSTRUCTIONS
From the 16-pin harness
• Connect the Yellow RCA to the backup camera input of the
aftermarket radio.
• Connect the Blue/Pink wire to the vehicle speed sense wire of the
aftermarket radio.
INTERFACE COMPONENTS
• 16-pin GMLAN29 backup camera harness.
INSTALLATION INSTRUCTIONS
From the 16-pin harness
• Connect the Yellow RCA to the backup camera input of the
aftermarket radio.
• Connect the Blue/Pink wire to the vehicle speed sense wire of the
aftermarket radio.
