Best Connectivity
www.LogiLink.
com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
PCI Express Card, 2 Serial ports
& 1 Parallel port
The majority of today´s motherboards are not equipped with any RS-232 or
parallel port. With Logilink PC0033 Multi I/O board, users can expand two
RS-232 and one IEEE1284 parallel ports to their system, allowing them to use
serial and parallel devices further. Furthermore, PC0033 Multi-IO card supports
majority of the OS on the market. We provide driver support for Microsoft
Windows 32/64-bit platform, Linux, making it the best and most economical
solution for commercial and industrial applications.
Art No. PC0033
Specification:
General
• Chipset: MOSCHIP MCS9901
• 2 serial ports & 1 Parallel Port
• Compliant with PCI-Express Revision
1.0a
• Single-Lane (x1) PCI-Express with
throughput up to 2.5Gbps
• Plug & Play and Hot Swappable
• Supports Windows 2000, 2003, XP 32-
/64-bit, Vista 32-/64-bit, 7/8/8.1/10,
Linux, Mac OS, and DOS
Serial Port (RS-232):
• Compatible with industrial standard
16C450/16C550 UART
• With 16-byte Transmit-Receive FIFO
• Fast Data Rates up to 1.0MBps
• Supports RS232 Hardware and Software
flow control
Parallel Port:
• Compatible with IEEE1284 printer port
• Supports SPP, PS2, EPP & ECP mode
• Fast data rates up to 1.5MBps
Packaging Information:
• Packing Dimension: 172x182x37 mm
• Packing Weight: 0.17kg
• Carton Dimension: 760x410x210 mm
• Carton Q'ty: 40pcs
• Carton Weight: 10kg
Problemløsning LogiLink PC0033
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Pakkevægt: | 170 g |
| Pakkedybde: | 182 mm |
| Pakkebredde: | 172 mm |
| Pakkehøjde: | 37 mm |
| Harmoniseret systemkode (HS): | 84733020 |
| Mac kompabilitet: | Ja |
| Bæredygtighedscertifikater: | RoHS |
| Formål: | PC |
| Understøttede Windows-operativsystemer: | Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Ultimate, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 |
| Understøttede Mac-operativsystemer: | Mac OS 9.1 |
| Understøttede Linux-operativsystemer: | Ja |
| Værtsgrænseflade: | PCIe |
| Intern: | Ja |
| Plug and play: | Ja |
| Flowkontrol support: | Ja |
| Seriel grænsefladetype: | RS-232 |
| Antal serielle porte: | 2 |
| Dataoverførselshastighed: | 2.5 Gbit/sek. |
| Output-grænseflade: | Parallel, Serial |
| Porte, antal: | 3 |
| Antal parallelle porte: | 1 |
| Chipsæt: | NetMOS |
| Overførselshastighed: | 1.5 MB/s |
| Understøtter EPP og ECP: | Ja |
