L100 Classic MkII
3-Way Bookshelf12-inch (300mm) Loudspeaker
Quick Start Guide
Overview
For more information on the set-up and operation of this
product refer to the product page on the jbl.com/specialty-audio/
website. Should further assistance be required feel free to
contact customer support at the numbers below.
Inside the US and Canada: +1 888.691.4171
Outside the US and Canada: +44 1707 668 012
Box Contents
1x L100 Classic Edition LoudspeakersMkII
2x Quadrex Foam Grilles
1x Quick Start Guide (This Document)
Placement and Positioning
●
Before deciding where to place your speakers, survey your room and think
about placement, using the illustration as a guide.
●
Avoid placing the speakers near power amplifiers, heat registers or other objects
that generate large amounts of heat.
●
Avoid placing speakers in humid or dusty locations.
●
Avoid placing speakers in direct sunlight or other intense light.
●
Refer to the illustration for distances from walls, between the speakers, and
angle to the listening position.
●
The speakers should be raised so that the tweeter is approximately at ear level.
The JS-120 or JS-150 speaker stand (sold separately) can be used to achieve
the proper listening height and angle.
●
Angle the speakers towards the listening position closer to the listeners ears for
a stronger center image and away from the listening position further from the
listeners ears for a more spacious image.
Specifications
Type: 12-inch (300mm) 3-way Bookshelf Loudspeaker
Low Frequency Driver: 12-inch (300mm) cast-frame Pure Pulp cone woofer with Dual
Spider (JW300SW-8)
Mid Frequency Driver:
5-1/4 inch (130mm) Polymer-coated, Pure Pulp cone
(JM125PC-8)
High Frequency Driver: 1-inch (25 mm) Titanium dome tweeter mated to acoustic lens
and wave guide (JT025Ti2-4)
Recommended
Amplifier Power:
25-200 Watts RMS
Impedance: 4 ohms
Loudspeaker Sensitivity: 90dB
Frequency Response: 40Hz-40kHz (-6dB)
Crossover Frequency: 450Hz, 3.5kHz
Finish:
Natural Walnut veneer with Black, Orange, or Blue Quadrex
Foam Grille
Dimensions (With Grille):
25. x 15.4 x 14. (6 mm x 389. mm x 3-inch -inch 4-inch 42.9 9
3 mm) 65.1
Controls: Attenuators for MF and HF Drivers
Input Type: Dual sets of Gold-plated Binding Posts
Product Weight (Each): 63
lb (2 kg) each8.6
Shipping Weight: 7
3 1 lb (33. kg) each
Shipping Units of Measure: Single Speaker
Recommended stand height: 7in (180mm)
Recommended Stand: JBL JS-120 or JS-150 (Sold Separately)
JBL L100 Classic MkII Quick Start Guide | Rev 3. 20230501 | Part No. 950-0624-0010
©2023 Harman International | Features, Specifications, and Appearance subject to change without notice.
Pg 1 of 2
20in
(51cm)
20in
(51cm)
6ft (1.8mm) to
8ft (2.4mm)
Angle speaker to suit
listening preference.
See Postioning Bullet
Listening Position
40° to 60°
