HARMAN Consumer, Inc.
8500 Balboa Boulevard, Northridge, CA 91329 USA
© 2011 HARMAN International Industries, Incorporated. All rights reserved.
JBL and Grand Touring are trademarks of HARMAN International Industries,
Incorporated, registered in the United States and/or other countries. Features,
specications and appearance are subject to change without notice.
Part #950-0353-001 Rev. A
INSTALLATION MANUAL
6" x 9" three-way car audio loudspeaker
GTO949 LIMITED EDITION
DIMENSIONS
ThIELE-SMALL PArAMETErS
3-15/16"
(100mm)
8-3/4"
(221mm)
2-15/16"
(74mm)
4-13/16"
(122mm)
6-1/2"
(165mm)
5-15/16"
(150mm)
11/16"
(17mm)
3-3/16"
(82mm)
9-1/4"
(235mm)
6-1/2"
(165mm)
BL (T.m)
4.64
DCR (ohms)
2.35
Mms (g)
23.00
Sd (cm
2
)
244.00
Cms (µm/N)
323.00
Vas (liters)
22.76
Fs (Hz)
58.40
Qes
0.92
Qms
9.24
Qts
0.84
SPECIFICATIONS
Type
6" x 9" (152mm x 230mm)
three-way loudspeaker
Power handling, continuous average
100W
Power handling, peak
400W
Frequency response
45Hz – 21kHz
Nominal impedance
2 ohms
Sensitivity (2.83V/m)
94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth.
Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Grand Touring
®
Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country
in which it was purchased. Your local JBL
®
car audio retailer can help you
determine the length of your warranty. To register your product, please visit
www.jbl.com.
