Montagehinweis Rundprofil
Installation note rod mounting
Notice de montage profil rond
ifm electronic gmbh . Friedrichstraße 1 . D 45128 Essen
Für die Adaption von Haltewinkeln sind
folgende Klemmzylinder verfügbar:
für Rundprofil Klemmzylinder
Ø 10 mm (E80310) E20843
Ø 12 mm (E20940) E20717
Ø 14 mm (E20941) E20795
The rod mounting (a) can be used for
aluminium profile mounting as well as for free
standing mounting.
For aluminium profile mounting a cube is
required additionally:
For rod mounting Cube
M8 (E80310) E20950
M10 (E20940) E20951
M12 (E20941) E20952
For the adaptation of mounting brackets the
following clamps are available:
For rod mounting clamp
Ø 10 mm (E80310) E20843
Ø 12 mm (E20940) E20717
Ø 14 mm (E20941) E20795
Le profil rond (a) peut être utilisée pour le
montage sur profil aluminium et sur platine.
Pour le montage sur profil aluminium vous
avez également besoin d' un cube:
Pour profil rond Cube
M8 (E80310) E20950
M10 (E20940) E20951
M12 (E20941) E20952
Pour l'adaptation d'équerres de fixation les
cylindres de serrage suivants sont disponibles:
Pour profil rond: cylindre de serrage
Ø 10 mm (E80310) E20843
Ø 12 mm (E20940) E20717
Ø 14 mm (E20941) E20795
Das Rundprofil (a) können Sie sowohl für die
Aluprofilmontage als auch für die
Flächenmontage verwenden.
Für die Aluprofilmontage benötigen Sie
zusätzlich einen Cube:
für Rundprofil Cube
M8 (E80310) E20950
M10 (E20940) E20951
M12 (E20941) E20952
