HC1A-FS/HS
01/19/24
Item # 13679
HC1A-FS/HS
One Section Full and Half Stainless Heated Cabinet
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
Interior top-mounted heating element
with fan to circulate heat through
cabinet; heat shield foamed in next to
heating element
Additional storage fits 12 sheet pans
Maximum interior storage capacity with
smallest external footprint
Hoshizaki reserves the right to change specifications without notice.
Item #:
Project:
Qty:
AIA#:
Features
Options
Dimensions / Capacity
Electrical / Refrigeration
One Section
HC1A-FS HC1A-HS
®
Interior Storage Capacity (CF) (AHAM)
Overall Width x Depth
Height
(including 4” casters)
Door Opening Width x Height
Depth with Door Open at 90º
Adjustable Shelves
Shelf Dimensions (W x D)
Crated Shipping Weight
Crated Length x Depth x Height
Voltage
HACR Breaker
Electrical Connection
(NEMA)
Voltage Range
Ambient Temp. Range
Control Setpoint Range
Amperage
Energy Consumption
(w) @ASTM 2140-11
22.70 ft
3
27.5” x 33.5”
79.5”
21.75” x 59.25”
59.25”
3
21.25” x 26”
340 lbs
37.5” x 31.5” x 81”
115/60/1
15.0 Amps
5-15P
104-126
45° to 100°F
140°-180°F
10
143.4
• Stainless steel interior with stainless exterior front,
sides, and top
• Energy efficient interior LED light
• Solid state digital controller with temperature alarms
and LED display (Fahrenheit or Celsius)
• Cabinet and doors are insulated with 2-3/8” of CFC
free, foamed in place polyurethane
• Exclusive stepped door design to protect recessed
door gasket (magnetic snap-in gasket)
• Self-closing doors with stay open feature
• One piece, full length handle
• Sturdy 8 gauge stainless steel hinge plate with welded
hinge pin
• Field reversible doors
• Door locks are standard
• Stainless steel shelf supports
• (3) epoxy coated wire shelves are standard
• A single section cabin can hold between 20-24 tray
slides depending on the product
• Standard with 4” casters (two with brakes)
• 10 ft. cord and plug
Additional epoxy shelves
Stainless steel shelves
2 Pan slides (HS-3557)
6 Pan slides (HS-5081)
8 Pan Slides (HS-3558)
Foot pedal (
Rt. Hinge HS-5379)
1 Wire slide (HS-5092)
4 Wire slides (HS-5093)
6” Adjustable legs
Valid in United States, Canada, Puerto
Rico and U.S. Territories. Contact factory
for warranty in other countries.
22.62 ft
3
27.5” x 33.5”
79.5”
21.75” x 27.75”
59.25”
3
21.25” x 26”
340 lbs
37.5” x 31.5” x 81”
One Section
HC1A-FS/HC1A-HS
W x D x H
27.5” x 33.5” x 79.5”*
*with 4” casters
HC1A-FS
HC1A-HS
If GFCI is required, a GFCI breaker MUST be used in lieu of GFCI receptacle
