RFH2-3-SSB
3/13
Item # 13255
RFH2-3-SSB
Professional Series Reach-in Dual Temps
nc. reserves the right to change
specifications without notice.
*AutoCad available on KCL
Item #
Project:
Qty:
• Stainless steel interior and exterior
• Energy efficient thermostatic expansion valve self contained refrigeration system
• EverCheck digital control system with audio alarms
• Entire cabinet is insulated with 2 3/8" foamed in place polyurethane
• Unique “ducted” air distribution system
• Self closing all stainless steel doors with locks
• Dual door frame heaters with energy saving on/off switch
• All metal torsion spring hinge design with stay open feature
• Exclusive "stepped" door design to protect recessed door gasket
• Flush mount door handles
• Field reversible doors (with optional kit)
• Epoxy coated evaporator coil
• Hinged upper front panel for easy access to controller
• Removable, cleanable refrigeration system air filter
• Energy efficient automatic hot gas condensate evaporator
• (3) Epoxy coated wire shelves per section
• Standard with 4" factory installed casters (2 with brakes)
• Three years parts and labor warranty
• Five year compressor warranty
© HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269
TEL 800-438-6087
FAX 800-345-1325
www.hoshizaki.com
RFH-SSB Dimensions
W x D x H
2 Section - 55” x 33.6” x 82.5”*
3 Section - 82.5” x 33.6” x 82.5”*
*with 4" casters
Electrical/Refrigeration
Voltage 115/60/1
HACR Breaker 30.0
Electrical Connection Hard-Wired
Junction Box
Voltage Range 104-126
Ambient Temp. Range 45˚-100˚F
Control Setpoint Range 36˚-50˚F (R)
-10˚ to +25˚F (F)
*Refrigerant R-404A
Warranty
Valid in United States, Canada, Puerto Rico,
and U.S. Territories. Contact factory for
warranty in other countries.
• Three Year - Parts & Labor on entire
machine.
• Five Year - Parts on: Compressor.
Options
• 6” legs with stainless steel bullet feet
• Door reversal kit
• Additional epoxy shelves
• Stainless steel shelves
• Patented foot pedal door opener
• Combination universal tray/pan slides
• Door padlock hasp
• NAFEM Data Protocol connection
(Software by other vendors)
Dimensions / Capacity
Electrical & Refrigeration Data
Model # Two Section
RFH2-SSB
Three Section
RFH3-SSB
Interior Storage Capacity (CF) 22.3 ft
3
ea. sec. (R & F) 48.0 ft
3
(R) / 22.3 ft
3
(F)
Overall Width x Depth 55” x 33.6” 82.5” x 33.6”
Height (including 4” casters) 82.5” 82.5”
Door Opening Width x Height 21.75” x 59.25” 21.75” x 59.25”
Depth with Door open at 90° 58.5” 58.5”
Adjustable Shelves 6 (3 ea.) 6 (R) / 3 (F)
Center Shelves - 3 (R)
Shelf Dimensions (W x D) 21.25” x 26” 21.25” x 26”
Crated Shipping Weight 750 lbs 950 lbs
Crated Height x Width x Depth 85” x 59” x 38” 85” x 87” x 38”
Model # Two Section
RFH2-SSB
Three Section
RFH3-SSB
Amperage
17 20.6
Energy Consumption (kwh/day)
12.9 17.1
Heat Rejection (BTU/Hr.)
2580 3035
Approx. Nominal Compres. BTU/HR(HP)
1490 (1/5HP) R / 2671 (2/3HP) F 1490 (1/5HP) R / 2671 (2/3HP) F
