SLIM-LINE MODULAR CRESCENT CUBER
KM-520/660MRJZ
11/12/21
Item # 13624
Item #:
Project:
Qty:
AIA#:
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
22" x 27
3/8
" x 28"
W x D x H
Features
Individual crescent cube
Factory-installed ultrasonic bin
control can be adjusted on site
Simple, one-hour cleaning process
• Durable construction with fewer parts
• Self-diagnostic programming automatically adjusts
to changing conditions
• Snap fit parts for easy cleaning
• Stainless steel double-sided evaporator
• CycleSaver
TM
design
• Protected by H-GUARD Plus
Antimicrobial Agent
• EverCheck
TM
alert system
• R-404A Refrigerant
TM
TM
®
CLEAN
ASSIST
Volume:
33.5” x 25.88” X 34.6” 16.64ft
3
Shipping: (LxWxH)
3 Year Parts & Labor on entire machine 5 Year Parts & Labor on evaporator
5 Year Parts on Compressor; air-cooled condenser coil
Valid in United States, Canada, Puerto Rico and U.S. Territories. Contact factory for
warranty in other countries.
Warranty:
†
(with condenser)
Remote Air-Cooled
KM-520MRJZ
KM-660MRJZ
Available on Bins/Dispensers:
Top kit may be required. See Bin Spec Sheets.
B-250SF
B-300SF
DB-130H
DB-200H
DM-200B
B-500/SF
B-700SF
B-1150SS
B-1300SS
B-800SF
B-900SF
547
646
KM-520MRJZ
495
602
13.6
14.7
N/A
N/A
4.80
5.60
20A
20A
6,200
8,100
145 / 175
150 / 180
115V/60/1
115V/60/1
Air / Water Temp
Lbs. per 24 hours
Condenser
Model
70°/ 50°F 90°/ 70°F
ICE PRODUCTION
Potable
Gal. per 100 lbs.
Condenser
Gal. per 100 lbs.
Heat
Rejection
BTU/hr.
Voltage
WATER USAGE
90°/ 70°F 90°/ 70°F
ELECTRICAL
90°/ 70°F
kWh Used
per 100 lbs.
Amperage
12.05A
16.1A
Circuit
Wires
(including ground)
3
3
Net / Ship
Weight (lbs.)
Refrigerant
Charge Amount
2 lb. 4.7 oz.
2 lb. 4.7 oz.
Remote
4 lb. 2.7 oz.
†
4 lb. 2.7 oz.
†
Min. Circuit
Amp - Max.
Fuse/Breaker
Remote
KM-660MRJZ
• Ambient Temp Range 45 - 100°F
• Water Temp Range 45 - 90°F
• Water Pressure 10 - 113 PSIG
• Voltage Range 104 - 127V
Operating Limits
Service
• Panels easily removed and all components
accessible for service.
• Removable/cleanable air filters. (Air-cooled model only)
• Allow 6” (15 cm) clearance at rear, sides, and top for
proper air circulation and ease of maintenance/service.
KM Edge Cube Dimensions
†
1
1/2
”
1/2
”
1
1/8
”
• Icemaker water supply line: minimum 1/2” nominal ID copper water
tubing or equivalent
• Icemaker drain line: minimum 3/4” nominal ID hard pipe or equivalent
Plumbing
Please refer to water filter specification sheet for recommendations.
Water Filter
†
approximate size in inches, image not to scale
Line Sets
• Line sizes for lengths up to 66’: 1/4” LIQ and 3/8” DIS
• Line sizes for lengths greater than 66’ to a maximum of 100’: 3/8” LIQ
and 1/2” DIS plus charge adjustment - add 16.5 oz. (468 g) of refrigerant
to compensate for larger diameter line sizes and 0.4 oz. (11 g) for each foot
over 66’.
