Side 1/2
HUR40/68/96A
3/13
Item # 13155
nc. reserves the right to change
specifications without notice.
*AutoCad available on KCL
Item #
Project:
Qty:
• Stainless steel interior and exterior top, front and sides
• EverCheck solid state digital control system with visual alarms
• Entire cabinet and doors are insulated with 2 3/8" CFC free foamed in place polyurethane
• Exclusive "Stepped" door design to protect recessed door gasket
• Self-closing all stainless steel doors with locks
• Doors are reversible at the factory (no charge)
• Dual door frame heaters to eliminate condensation
• Epoxy coated evaporator coil
• Front breathing with Zero clearance requirements
• Cartridge-style refrigeration system is easily removed from main unit
• Defrost is time initiated temperature terminated
• Hinged, louvered front panel for easy access to controller
• Removable stainless steel end panel for access to refrigeration system
• Removable, cleanable refrigeration system Air Filter
• Energy efficient automatic hot gas condensate evaporator
• (1) Epoxy coated wire shelf per section
• Stainless steel shelf supports adjustable on 1” centers
• 4" heavy duty platform casters (two with brakes)
• Three years parts and labor warranty
• Five year compressor warranty
• 8 ft. cord and plug
HUR-A Dimensions
W x D x H
1 Section - 40.25” x 32.3” x 33.9”*
2 Section - 68” x 32.3” x 33.9”*
3 Section - 95.8” x 32.3” x 33.9”*
*with 4” casters
Electrical/Refrigeration
Voltage - 115/60/1
HACR Breaker - 15.0
Electrical Connection - 5-15P
(NEMA)
Voltage Range - 104-126
Ambient Temp. Range - 45˚-100˚F
Control Setpoint Range - +21˚to +53˚F
*Refrigerant R-134a
Warranty
Valid in United States, Canada, Puerto Rico,
and U.S. Territories. Contact factory for
warranty in other countries.
• Three Year - Parts & Labor on entire
machine.
• Five Year - Parts on: Compressor.
Options
• 6” Legs
• 6” Casters
• Tray pan rack slides (18” x 26” pans)
• Bullnose top (front & rear)
• Stainless steel back
• Drawers
• Additional epoxy shelves
Dimensions / Capacity
Electrical & Refrigeration Data
Model # One Section
HUR40A
Two Section
HUR68A
Three Section
HUR96A
Interior StorageCapacity (CF) 8.5 ft
3
18.8 ft
3
29.1 ft
3
Overall Width x Depth 40.25” x 32.3” 68” x 32.3” 95.8” x 32.3”
Height (including 4” casters) 33.9” 33.9” 33.9”
Door Opening Width x Height 22.5” x 24.3” 22.5” x 24.3” 22.5” x 24.3”
Depth with Door open at 90° 56.8” 56.8” 56.8”
Adjustable Shelves 1 2 3
Shelf Dimensions (W x D) 22.4” x 24.6” 25.0” x 24.6” 25.9” x 24.6”
Crated Shipping Weight 312 lbs 435 lbs 558 lbs
Crated Height x Width x Depth 39.5” x 44.25” x 36.25” 39.5” x 72” x 36.25” 39.5” x 99.75” x 36.25”
Model # One Section
HUR40A
Two Section
HUR68A
Three Section
HUR96A
Amperage
5.0 5.0 6.0
Energy Consumption (kwh/day)
2.44 2.77 4.50
Heat Rejection (BTU/Hr.)
449 638 740
Approx. Nominal Compres. BTU/HR(HP)
1442 (1/5HP) 1442 (1/5HP) 2010 (1/4HP)
HUR40/68/96A
Professional Series Undercounter Refrigerators
© HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269
TEL 800-438-6087
FAX 800-345-1325
www.hoshizaki.com
