HUF40/68A
5/11/16
Item # 13157
nc. reserves the right to change
specifications without notice.
*AutoCad available on KCL
Item #
Project:
Qty:
• Stainless steel interior and exterior top, front and sides
• EverCheck solid state digital control system with visual alarms
• Entire cabinet and doors are insulated with 2 3/8" CFC free foamed in place polyurethane
• Exclusive "Stepped" door design to protect recessed door gasket
• Self-closing all stainless steel doors with locks
• Doors are reversible at the factory (no charge)
• Dual door frame heaters to eliminate condensation
• Epoxy coated evaporator coil
• Front breathing with Zero clearance requirements
• Cartridge-style refrigeration system is easily removed from main unit
• Defrost is time initiated temperature terminated
• Hinged, louvered front panel for easy access to controller
• Removable stainless steel end panel for access to refrigeration system
• Removable, cleanable refrigeration system Air Filter
• Energy efficient automatic hot gas condensate evaporator
• (1) Epoxy coated wire shelf per section
• Stainless steel shelf supports adjustable on 1” centers
• 4" heavy duty platform casters (two with brakes)
• Three years parts and labor warranty
• Five year compressor warranty
• 8 ft. cord and plug
HUF-A Dimensions
W x D x H
1 Section - 40.25” x 32.3” x 33.9”*
2 Section - 68” x 32.3” x 33.9”*
*with 4” casters
Electrical/Refrigeration
Voltage - 115/60/1
H
ACR Breaker - 15.0
E
lectrical Connection - 5-15P
(NEMA)
Voltage Range - 104-126
Ambient Temp. Range - 45˚-100˚F
Control Setpoint Range - -13˚ to +19˚F
*Refrigerant R-404A
Warranty
Valid in United States, Canada, Puerto Rico,
and U.S. Territories. Contact factory for
warranty in other countries.
• Three Year - Parts & Labor on entire
machine.
• Five Year - Parts on: Compressor.
Options
• 6” Legs
• 6” Casters
• Tray pan rack slides (18” x 26” pans)
• Bullnose top (front & rear)
• Stainless steel back
• Drawers
• Additional epoxy shelves
Dimensions / Capacity
Electrical & Refrigeration Data
Model # One Section
HUF40A
Two Section
HUF68A
Interior Storage Capacity (CF) 8.5 ft
3
18.8 ft
3
Overall Width x Depth 40.25” x 32.3” 68” x 32.3”
Height (including 4” casters) 33.9” 33.9”
Door Opening Width x Height 22.5” x 24.3” 22.5” x 24.3”
Depth with Door open at 90° 56.8” 56.8”
Adjustable Shelves 1 2
Shelf Dimensions (W x D) 22.4” x 24.6” 25.0” x 24.6”
Crated Shipping Weight 317 lbs 442 lbs
Crated Height x Width x Depth 39.5” x 44.25” x 36.25” 39.5” x 72” x 36.25”
Model # One Section
HUF40A
Two Section
HUF68A
Amperage
4.8 10.0
Energy Consumption (kwh/day)
4.97 9.45
Heat Rejection (BTU/Hr.)
1133 1565
Approx. Nominal Compres. BTU/HR(HP)
1378 (3/8HP) 2466 (1/2HP)
HUF40/68A
Professional Series Undercounter Freezers
© HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269
TEL 800-438-6087
FAX 800-345-1325
www.hoshizaki.com
