DS-PI-Q75
DS-PI-Q100
DS-PI-Q150
DS-PI-Q200
DS-PI-Q250
QUADRUPLE BEAM PHOTOELECTRIC DETECTOR
INSTRUCTION MANUAL
DS-PI-Q75 75m 2.0m
DS-PI-Q100 100m 3.0m
DS-PI-Q150 150m 4.5m
DS-PI-Q200 200m 6.0m
DS-PI-Q250 250m 7.5m
DS-PI-Q75/
DS-PI-Q100
DS-PI-Q200/
DS-PI-Q250
DS-PI-Q150
DS-PI-Q75 DS-PI-Q100 DS-PI-Q150 DS-PI-Q200 DS-PI-Q250
-25°C~+55°C
65mA
750m
75m
70mA
1000m
100m
90mA
1500m
150m
95mA
2000m
200m
100mA
2500m
250m
180°(±90°)
24°(±12°)
Peep window
Slit type mask, optional heater
Sensitivity to monitor output terminals, OK indicator
PC front cover; ABS Back Cover
Contact Output 1b DC 30V 0.05A max
4 beams Intercepted simultaneously
4 beams
Model
Alarm Distance
Max reaching distance
Beams NO.
Detecting Way
Light Source
Response Time
Alarm Output & DQ Output
Supply Voltage
Supply Current
Operation Temperature Range
Tamper Output
Optic axis adjust angle (Horizontal)
Optic axis adjust angle (Vertical)
Sight
Strategy to dew/frost
Other additional functions
Material
Weight
Attachment Self-tapping screw: eight, filter: 2 slices
IR LED
35~700ms
FORM C(NO/NC changeable), Contact ratings DC 30V 0.5A max.
DC10.5~28V(non-polarity)
Recommend supply Voltage
DC 12V or 24V(non-polarity)
Around 1970g ( Transmitter and Receiver )
353mm×99mm×104mm
Dimensions (H×W×D)
Green level is on
Problemløsning Hikvision DS-PI-Q75
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 99 mm |
| Dybde: | 104 mm |
| Højde: | 353 mm |
| Vægt: | 1970 g |
| Produktfarve: | Sort |
| Husmateriale: | Acrylonitrilbutadienstyren |
| Udgangsspænding: | 10.5 - 28 V |
| Transmissionsafstand: | 750 m |
| Opdagelsesafstand: | 75 m |
| Gear rækkevidde: | 0 - 750 m |
