DUAL BEAM SELECTABLE FREQUENCY
PHOTOELECTRIC DETECTOR
INSTRUCTION MANUAL
82
83
194.5
φ38mm~φ47mm
1.45V
④
Horizontal optical
axis knob
Frequency Channel
The transmitter and the receiver select the
same channel.
DS-PI-D30/FM
DS-PI-D40/FM
DS-PI-D60/FM
DS-PI-D80/FM
DS-PI-D100/FM
DS-PI-D30/FM 30m 0.9m
DS-PI-D40/FM 40m 1.2m
DS-PI-D60/FM 60m 1.8m
DS-PI-D80/FM 80m 2.4m
DS-PI-D100/FM 100m 3.0m
DS-PI-D30/FM DS-PI-D40/FM DS-PI-D60/FM DS-PI-D80/FM DS-PI-D100/FM
DS-PI-D30/FM DS-PI-D40/FM DS-PI-D60/FM DS-PI-D80/FM DS-PI-D100/FM
80m30m 40m 60m
300m
45mA 45mA 50mA 55mA 55mA
100m
800m400m 600m 1000m
and ALARM (Red)
:blink when signal is weak
-25°C~+60°C
180°(±90°)
20°(±10°)
one-piece
Ultrasonic structure
Receiving light Indicate OK Indicate Testing Terminal、 、
PC front cover; ABS Back Cover
Contact Output 1b DC 30V 0.05A max
2 beams Intercepted simultaneously
2 beams
Model
Alarm Distance
Max reaching distance
Beams NO.
Detecting Way
Light Source
Response Time
Alarm Output
Supply Voltage
Supply Current
Operation Temperature Range
Tamper Output
Optic axis horizontal adjust
Optic axis vertical adjust
Sight
Strategy to dew/frost
Other additional functions
Material
Weight
IR LED
50~500ms
Channel Choice
4 Channels CH1~CH4
FORM C(NO/NC changeable), Contact ratings DC 30V 0.5A max.
DC10.5~24V (non-polarity)
Recommend supply Voltage
DC 12V (non-polarity)
Around 850g ( Transmitter and Receiver )
194.5×83×82mm
Dimensions (H×W×D)
Problemløsning Hikvision DS-PI-D80/FM
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 83 mm |
| Dybde: | 82 mm |
| Højde: | 194.5 mm |
| Vægt: | 850 g |
| Produktfarve: | Sort |
| Husmateriale: | Acrylonitrilbutadienstyren |
| Udgangsspænding: | 10.5 - 24 V |
| Omgivelsestemperatur (min): | -25 °C |
| Omgivelsestemperatur (maks): | 60 °C |
| Gear rækkevidde: | 0 - 800 m |
