Hikvision DS-7208HQHI-K1 Brugsanvisning
Her er Hikvision DS-7208HQHI-K1 (Diktafon) brugervejledning. 3 sider på sprog Engelsk med en vægt på 0.3 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/3
DS- HQHI-K1 SERIES TURBO HD DVR 7200
Video Input and Transmission
Self-adapve HDTVI/HDCVI/AHD/CVBS signal input
Up to 2-ch 4 MP IP cameras input
Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression and Recording
H.265+/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
Connectable to H.265+/H.265/H.264+/H.264 IP cameras
H.265+ can be enabled to improve encoding eciency and reduce data storage costs
Up to 3 MP resoluon for recording
Supports real-me 1080p lite and when enabled, the image eect is similar with 1080p
Video Output
Simultaneous HDMI/VGA output
HDMI output at up to 4K (3840 × 2160) resoluon for DS-7216HQHI- K1
Separate CVBS output
Storage and Playback
1 SATA interface (up to 6 TB capacity per HDD)
4/8/16-ch synchronous playback
Smart search for ecient playback
Supports the 3rd party cloud storage (Dropbox/Google Drive/Microso OneDrive)
Smart Funcon
Supports lple VCA (Video Content Analycs) events for both analog and smart IP cameras mu
DS-7204/7208HQHI-K1 support 2-ch line crossing detecon and intrusion detecon; DS-7216HQHI-K1 supports 2-ch line
crossing detecon and intrusion detecon, and 1-ch sudden scene change detecon
VQD (Video Quality Diagnoscs)
Supports PTZ control via Omnicast VMS of Genetec protocol
Network & Ethernet Access
Hik-Connect DDNS (Dynamic Domain Name System) for easy network management &
1 RJ45 10M/100M Ethernet network interface for DS-7204/7208HQHI-K1, and 1 RJ45 10M/100M/1000M Ethernet
network interface for DS-7216HQHI- K1
Output bandwidth limit congurable
Features and Funcons
Problemløsning Hikvision DS-7208HQHI-K1
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vægt: | 1780 g |
| Produktfarve: | Sort |
| Relativ luftfugtighed ved drift (H-H): | 10 - 90 % |
| Format til analogt signal: | NTSC, PAL |
| Antal HDMI-porte: | 1 |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 2.0-porte: | 2 |
| Ethernet LAN: | Ja |
| Strømforbrug (typisk): | 7.5 W |
| Driftstemperatur (T-T): | -10 - 55 °C |
| Dimensioner (BxDxH): | 315 x 242 x 45 mm |
| Hurtig start guide: | Ja |
| Lyd-output kanaler: | 1.0 kanaler |
| Understøttede netværksprotokoller: | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF |
| Video komprimeringsformater: | H.264, H.264+, H.265, H.265+ |
| Lydindgang: | 1 |
| Spænding: | 12 V |
| Ethernet-grænsefladetype: | Hurtigt ethernet |
| HDD-grænseflade: | SATA |
| Lydudgang: | 1 |
| BNC-indgangsporte: | 1 |
| RS-485-porte: | 1 |
| Antal understøttede HHD'er: | 1 |
| Video indgang: | 1 |
| Video indgangskanaler: | 8 kanaler |
| Maksimal HDD-kapacitet: | 6000 GB |
| VGA (D-Sub) udgangsporte: | 1 |
