INSTRUCTION SHEET
©2016 Electrolux Home Products, Inc. Instruction Sheet 297357401 09.9.16
U19 All Refrigerator and All Freezer Trim Kit Installation 84”
NOTE: All Hardware Pack components mentioned throughout
this instruction sheet will have an “H” after the item number.
Parts Included in Single Trim Kit ECP8436SS
Product Line: U19 All Refrigerator and All Freezer Models
Models:
Serial Number Range: All Serial number ranges
EI32AR65JS E32AR75JPS E32AR85PQS EI32AR80QS
EI32AF65JS E32AF75JPS E32AF85PQS EI32AF80QS
ECP8436SS TRIM KIT 201SS
U19 84” X 36”
SERVICE
PART
ITEM DESCRIPTION QTY YES/NOPART NUMBER
1 297393200 Trim Side RH U19 201SS 8436 1 YES
2 297393201 Trim Side LH U19 201SS 8436 1 YES
3 297393300 1 YESGrille 201SS louvered single 8436
4 297336900 1 YESCenter trim U19
5 297393500 Kick Plate U19 Single tall 8436 1 YES
6 --------- Carton (Packaging) 1 NO
7 297390802 Hardware Pack Single U19 201SS 8436 1 YES
8 297276900 Leveler Assembly Support System 2 YES
8
3
2
1
5
297390803 HARDWARE PACK SINGLE TRIM KIT U19
MODEL NO. ECP8436SS LEVELERSWITH
ITEM DESCRIPTION QTYPART NUMBER
1H 297333900 1Tie-Bar Hinge
3H 297236250 8Screw HWD ¼ -20 X .63
5H 216036601 6Screw RWHD #8 - 32 X .50 Extruding
6H 216050507 Screw RWHD #10 - 32 X 9/16 Drilling 16
7H 297357400 I 1nstallation Instructions U19 SS Trim Kit
Hardware Pack 297390802
