Quick Start Guide
This guide contains important information.
Please keep it for future reference.
Scan the QR code
for more online
support:
Or go to service.gigaset.com
Important Safety Instructions
The applied nameplate is located at the bottom of the baby unit
base.
When in use, basic safety precautions should always be followed
to reduce the risk of re, electric shock and injury, including the
following:
1. Follow all warnings and instructions marked on the product.
2. Adult setup is required.
3. CAUTION: Do not install the baby unit at a height above 6.5 feet
(2 meters).
4. This product is intended as an aid. It is not a substitute for
responsible and proper adult supervision and should not be
used as such.
5. This product is not intended for use as a medical monitor.
6. Do not use this product near water, for example, near to a bath,
sink, swimming pool or shower.
7. CAUTION: Use only the internal, non-user replaceable battery
tted to the parent unit. There may be a risk of explosion if a
wrong type of battery is used for the parent unit. The battery
cannot be subjected to high or low extreme temperature
and low air pressure at high altitude during use, storage or
transportation. Disposal of batteries in re or a hot oven,
mechanically crushing or cutting the battery can result in an
explosion. Subjecting products or batteries to an extremely high
temperature environment can result in explosion or leakage of
ammable liquids, or gas. Products or batteries subjected to
extremely low air pressures may result in explosion or leakage
of ammable liquids, or gas. Dispose of used batteries according
to the information in The RBRC seal.
8. Use only the power adapters supplied with this product.
Incorrect power adapter polarity or voltage can seriously
damage the product.
Power adapter information:
Parent unit output: 5V DC 1A
VTech Telecommunications Ltd.
Model: VT05EUS05100
-OR-
Jiangxi Jian Aohai Technology Co., Ltd.
Model: A318-050100W-US2
Baby unit output: 5V DC 600mA.
VTech Telecommunications Ltd.
Model: VT05EUS05060
Rechargeable battery information:
Zhuhai Great Power Energy Co., Ltd.
Li-ion battery, 3.6V, 2600mAh, 9.36Wh;
Model: ICR18650-2.6Ah-3.6V-1S1P
-OR-
Guangdong Yungbang New Energy Co., Ltd.
Model: ICR18650_1S1P_3.6V_2600mAH
9. The power adapter is intended to be correctly oriented in a
vertical or oor mount position. The prongs are not designed
to hold the plug in place if it is plugged into a ceiling, under-
the-table or cabinet outlet.
10. For pluggable equipment, the socket-outlet (power adapter)
should be installed near the equipment and should be easily
accessible.
11. Unplug this product from the wall outlet before cleaning.
Do not use liquid or aerosol cleaners. Use a damp cloth for
cleaning.
12. Do not modify the power adapters or replace with other third-
party adapters.
13. Do not allow anything to rest on the power cords. Do not install
this product where the cords may be walked on or damaged.
14. The product should only be operated from a power source
indicated on the power adapter label or marking. If you are
unsure of the type of power supply in your home, consult your
dealer or electricity supply provider.
15. Do not overload wall outlets or use an extension cord.
16. Do not place this product on an unstable table, shelf, stand or
other unstable surfaces.
17. This product should not be placed in any area where proper
ventilation is not provided. Any slots or openings in the back
or bottom of this product are provided for ventilation. To
protect from overheating, openings must not be blocked by
placing the product on a soft surface such as a bed, sofa or rug.
This product should never be placed near or over a radiator or
heat source.
18. Never insert any objects through any apertures or slots in the
product as this can be dangerous and cause damage to the
battery or other internal parts. Never spill any liquids on the
product.
19. To reduce the risk of electric shock, do not disassemble
this product, but take it to an authorised service facility.
Disassembling or removing parts of the product other than
battery replacement via a battery door (if applicable) may
expose dangerous voltages or other risks.
20. You should test the sound reception every time you turn on
the units or move one of the components.
21. Periodically examine all components for damage.
22. There is a very low risk of privacy loss when using certain
electronic devices, such as baby monitors, cordless
telephones, etc. To protect your privacy, make sure the
product has never been used before purchase, reset the baby
monitor periodically by powering o and then powering
on the units, and power o the baby monitor if you are not
intending to use it for some time.
23. Children should be supervised to ensure that they do not
play with the product.
24. The small parts of this monitor can be swallowed by babies or
small children. Keep these parts out of reach of children.
25. The product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
SAVE THESE INSTRUCTIONS
Cautions
• Use and store the product at a temperature between 32
o
F
(0
o
C) and 104
o
F (40
o
C).
• Mishandling batteries can cause burn, re or explosion hazards.
• Batteries should not be exposed to excessive heat such as
bright sunshine or re.
• Do not expose the product to extreme cold, heat or direct
sunlight. Do not place the product close to a heating source.
•
Warning—Strangulation Hazard—
Children have STRANGLED in cords. Keep this
cord out of the reach of children (more than
0.9m away). Do not remove warning label on the
adapter cord.
• Never place the baby unit inside the baby’s cot or playpen.
Never cover the baby unit or parent unit with anything such as
a towel or a blanket.
• Other electronic products can cause interference to your
parent unit and baby unit. Try installing your baby unit as far
away as possible from the following electronic devices: wireless
routers, radios, mobile telephones, intercoms, room monitors,
televisions, personal computers, kitchen appliances (e.g.
microwave ovens) and cordless telephones.
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless devices):
Wireless Technology Research, LLC (WTR), an independent
research entity, led a multidisciplinary evaluation of the
interference between portable wireless devices and implanted
cardiac pacemakers. Supported by the U.S. Food and Drug
Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches from the
pacemaker.
• Should NOT place wireless devices directly over the pacemaker,
such as in a breast pocket, when it is turned ON.
WTR’s evaluation did not identify any risk to bystanders with
pacemakers from other persons using wireless devices.
Electromagnetic elds (EMF)
This VTech product complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according
to the instructions in this user’s manual, the product is safe to be
used based on scientic evidence available today.
Notes:
• Before using the baby monitor for the rst time, charge the Parent Unit battery for 12 hours. When the
Parent Unit battery is fully charged, the battery icon segments become solid .
• The standby time varies depending on your actual usage time and the age of the battery.
Battery Indicators Battery Status Action
The screen displays .
The red light ashes.
The battery has very little charge
and may be used for only a short
time.
Charge
without interruption
(about 30 minutes).
The battery icon segments
are solid .
The battery is fully charged.
To keep the battery charged,
connect it to AC power when
in use.
1. Connect the baby unit to a
power supply to turn it on.
Disconnect the baby unit to
turn it o.
2. The Parent Unit turns on automatically
after connecting to the power socket,
and the welcome screen appears.
You can press and hold POWER to turn
it on or o.
2. Charge the Parent Unit Battery
3. Power On or O the Baby Monitor
The battery icon on the screen indicates the battery status:
3
4. Status Check
Once your Baby Unit and Parent Unit are powered on and connected, your Parent
Unit displays video from the Baby Unit. The green Link LED light ashes and
turns on steady when connected.
1
5. Positioning the Baby Monitor
2
Note:
To avoid interference from other
electronic devices, place your baby
monitor at least 3 feet (1 meter) away
from devices such as wireless routers,
microwave ovens, mobile phones and
computers.
Caution:
The default volume of your Parent Unit is
level 3, and the maximum volume is level 5.
If you experience any feedback noise from
your baby monitor while positioning:
- Make sure your Baby Unit and Parent
Unit are more than 3 feet (1 meter)
apart, OR
- Lower the volume of your Parent Unit.
4
Visit our website www.gigaset.com
for more information about products, downloads, resources
and more.
Gigaset VS280
Video Baby Monitor
Press and hold
Quick Start Guide
1. Connect the Baby Monitor
What’s Included
Connect, Charge, and Power On the Baby Monitor
Strangulatio
n
Hazard
Keep this cord
out of reach of children.
The co
r
d ne
eds to be at least three
f
ee
t
away fr
o
m the child at all times. Do
not
use with an extension cord. Do not
re
move this ta
g.
Élo
ignez ce cordon des enfants. Le
cordon doit se trouver à au moins trois
pieds d’un enfant et ce, en tout temps.
N’
ut
ilisez
pas
d
e ra
llon
ge.
N
e
re
t
ir
ez
pas
cette étiquette.
M
an
tenga este cable f
u
era de la alcance
de los niños. Este cable debe est
ar por
lo menos tres pies fuera de la alca
nce
del
niño
en todo momento
. No lo
u
se
con
u
n
a e
xtensión inalámbrica. N
o
quite
es
t
a etiqueta.
Risque
d’
étr
anglement
Riesgo de
est
ra
ngula
c
ión
Strangulatio
n
Hazard
Keep this cord
out of reach of children.
The co
r
d ne
eds to be at least three
f
ee
t
away fr
o
m the child at all times. Do
not
use with an extension cord. Do not
re
move this ta
g.
Éloignez ce cordon des enfants. Le
cordon doit se trouver à au moins trois
pieds d’un enfant et ce, en tout temps.
N’
ut
ilisez
pas
d
e ra
llon
ge.
N
e
ret
ir
ez
pas
ce
tte étiquette.
M
an
tenga este cable f
u
era de la alcance
de los niños. Este cable debe est
ar por
lo menos tres pies fuera de la alca
nce
del niño
en todo momento. No lo
u
se
con
u
n
a e
xtensión inalámbrica. N
o
quite
es
t
a etiqueta.
Risque
d’
étr
anglement
Riesgo de
est
ra
ngula
c
ión
≥
<
3ft (1m)
3ft (1m)
Overview
1
3
5
6
7
9
8
4
2
11
12
10
1 Antenna
2 3-level sound indicator
light
3 Battery LED light
4 • Arrow keys
• /
5 MENU
• Press to enter the main
menu.
• While in a menu, press
to conrm a selection, or
save a setting.
6 Link LED light
• On when the parent unit
is linked to the baby unit.
• Flashes when the link to
the baby unit is lost.
7
TALK /
• Press and hold to talk to
the baby unit.
• While in a submenu, press
to exit.
8 POWER/LCD OFF
9
Microphone
10 Power jack
11 RESET
• Force reboot the
parent unit.
12 Speaker
1
2
4
5
6
7
9
3
8
1
2
4
5
6
7
9
3
8
1
2
4
5
6
7
9
3
8
1
Light Sensor
2
Camera lens
3
Infrared LED
4
Microphone
5
Power jack
6
Speaker
7
PAIR hole
• The parent unit and
baby unit provided
are already paired.
Parent Unit
Baby Unit
8 POWER LED light
9 Slots for wall
mounting
You will nd the quick start guide in
digital form under Downloads.
Problemløsning Gigaset VS280
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Mærke: | Gigaset |
| Kategori: | Babyalarm |
| Model: | VS280 |
