Gigabyte Luxo X140 Brugsanvisning
Her er Gigabyte Luxo X140 (Computerbehuizing) brugervejledning. 1 sider på sprog med en vægt på 677,413.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/1
¨
eSATA (Optional)
¦ Audio Jacks
HDD Drive Installation
4.
Power Supply Installation
5.
Motherboard Installation
1.
The Front Panel consists of
(1) 2 x USB2.0 (2) Audio Jack (3) eSATA (4) Power SW / LED connectors
Incorrect connector installation may possibly burn out the motherboard and other components. Be sure to
observe the instructions on installation manual. Any loss caued by nonobservance of the proper operation
provided is not covered by the warranty.
The connector or socket varies with different motherboards. For detailed instructions, please refer to the
instructions provided by the motherboard manufacturer.
Installation of Front Multi-Media
I/O Ports
¥ 2xUSB 2.0
Be sure that different motherboards may have different installation positions. For detailed instructions,
please refer to the instructions supplied by the motherboard manufacture.
Hardware Installation
Add-on card Installation
2.
5.25” and 3.5” Drives Installation
3.
Accessory
(Refer to the figures below for the attachments in the accessory )
Motherboard /
HDD Securing
Screws x 14
CD-ROM Securing
Screws x 6
Motherboard
Stand Off x 2
Power Bracket
x 1
Power Supply
Securing Screws
x 4
User Guide For
LU XO Series
Installation of power bracket
6.
§
ATX 12V CPU Connector
2
Lock
3
UnLock
2
1
4
5
1
1
3
BLACK
YELLOW
BLACK
YELLOW
BLACK
YELLOW
BLACK
YELLOW
Power Bracket
Securing Screws
x 2
2
1
2
1
2
KEY 87
Line Out(L)NC 109
MIC
MIC Power
Line Out(R)NC
GND 2
4
1
3
65
NC
NC
LINE2_R
GND
MIC2_R
FSENSE1 5 6
7
9
8
10
3
1
KEY
4
MIC2_L2
-ACZ_DET
FAUDIO_JD
LINE2_LFSENSE2
USB Over current
USB Dy+
USB Dx-
Power
KEY
USB Dx+
USB Dy-
Power
GND GND
87
109
2
4
1
3
65
4
1
3
2
6
5
7
SATA
HD AUDIO AC’97USB
Problemløsning Gigabyte Luxo X140
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | PC |
| Bredde: | 190 mm |
| Dybde: | 475 mm |
| Højde: | 415 mm |
| Vægt: | 4600 g |
| Produktfarve: | Sort |
| Formfaktor: | Midi Tower |
| Antal USB 2.0-porte: | 2 |
| Certificering: | RoHS |
| Lydindgang: | Ja |
| Lydudgang: | Ja |
| Vægt (efter britisk standard): | 10.1 Pund |
| Udvidelsesporte: | 7 |
| Eksterne drevbåse: | 3x 5.25", 2x 3.5" |
| Interne drevbåse: | 4x 3.5" |
| Udluftningsventilator (er): | 1x 12cm |
| Valgfri blæsere: | 1x 12cm |
