When you installing AGP card, please make sure the following notice
is fully understood and practiced. If your AGP card has "AGP 4X/8X
(1.5V) notch"(show below), please make sure your AGP card is AGP
4X/8X.
Caution: AGP 2X card is not supported by nVIDIA® nForce™ 2 IGP/SPP.
You might experience system unable to boot up normally. Please
insert an AGP Pro 4X/8X card.
Example 1: Diamond Vipper V770 golden finger is compatible with 2X/4X
mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X(1.5V) mode
by adjusting the jumper. The factory default for this card is 2X(3.3V). The
GA-7NNXPV / GA-7NNXP / GA-7N400V Pro / GA-7N400 Pro / GA-7N400-
L1 (or any AGP Pro 4X/8X only) motherboards might not function properly, if
you install this card without switching the jumper to 4X(1.5V) mode in it.
Example 2: Some ATi Rage 128 Pro graphics cards made by "Power Color",
the graphics card manufacturer & some SiS 305 cards, their golden finger is
compatible with 2X(3.3V) / 4X(1.5V) mode AGP slot, but they support
2X(3.3V) only. The GA-7NNXPV / GA-7NNXP / GA-7N400V Pro / GA-7N400
Pro / GA-7N400-L1 (or any AGP Pro 4X/8X only) motherboards might not
function properly, If you install this card in it.
Note : Although Gigabyte's AG32S(G) graphics card is based on ATi Rage
128 Pro chip, the design of AG32S(G) is compliance with AGP 4X(1.5V)
specification. Therefore, AG32S(G) will work fine with nVIDIA ® nForce2 IGP/
SPP based motherboards.
Before you install PCI cards, please remove the Dual BIOS label from PCI
slots if there is one.
AGP 4X/8X notch
Problemløsning Gigabyte GA-7NNXP
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Strømkilde type: | ATX |
| Maksimal intern hukommelse: | 3 GB |
| Medfølgende software: | Norton Internet Security \nNorton Anti Virus \nNorton Personal Firewall \nNorton Privacy Control \nNorton Parental Control \nNorton Spam Alert \nGIGABYTE Windows Utility Manager \nAdobe Acrobat Reader \nAdobe Acrobat e-Book Reader |
| Processorproducent: | AMD |
| I/O-porte: | PS/2 Keyboard / Mouse \n4 x USB 2.0/1.1 ports \n2 x RJ45 ports \n2 x COM ports \n1 x LPT \nAudio (1 x Line-in / 1 x Line-out / 1 x Mic) connector\n |
| Netværksfunktioner: | Realtek 8201 LAN PHY Chip |
| Lydudgang: | Realtek ALC650/655 Audio AC'97 Codec |
| Udvidelsesporte: | 1 x AGP Pro slot (8x/4x-AGP 3.0 compliant, supports 1.5v display card only.) \n5 x PCI slots (PCI 2.2 compliant) \n1 x DPS slot |
| Processor sokkel: | Sokkel A(462) |
| Motherboard form faktor: | ATX |
| Controller-grænsefladetype: | GigaRAID ATA 133 RAID controller |
