Brake resistor - BWD600 LIP65FE080K03
CACR- - - KL2 240 W1800
*Sc
Description:
Short protecting- -proof, -circuit self 1) resistor unit for operation on converters (brake transistors) consisting of
3 resistor modules in anodized aluminium casings. Protection class according to IP652), interconnected by
spring- type terminals. For detailed measurements, see technical drawing (on request).
Nominal capacity (W)
Dimensions LxWxH (mm)
Resistance values (Ohm)
72 180 ( 00 at ED = 35%, ϑA
= 20°C)
229 91 x 216 x ,5
240
Technical data:
Parameters
Symbol
Value
Unit
Conditions
Tolerance
± 5
%
Room temperature
Weight
m
approx 4,5
kg
Connction data terminal
Conductor cross- section
6 Max. mm2
Depending on the design of the cable
cross- section
Storing temperature
ϑS
- 25 ... +85
°C
Limit values (ϑA )= 20°C, if nothing else is stated :
Parameters
Symbol
Value
Unit
Conditions
Max. permissible operating
voltage
U
B
≤
700 AC
≤ 1000 DC
V
considering “self protection” 1)
U
B
≤ 600 AC# *
≤
8 50 DC*
V
considering CSA# and UL*
Energy consumption
E
13
26
kJ
with 1,2s (1% ED)
with 7,2s (6% ED)
Insulation voltage
UISO
≥ 4000
V
AC; f = 50 Hz; t = 1 s
Max. permissible casing
temperature
ϑC
≤
250
°C
free convection
Temperature coefficient
TK
20 ... 100
10-6/K
Insulation resistance
RISO
≥ 100
M Ω
UMEAS = 1000 VDC
Inductance
L
≤ 30
µH
f = 300 kHz, UMEAS = 50 mV
Capacity against housing
C
≤ 300
pF
f = 300 kHz, UMEAS = 50 mV
Thermic time factor
τ
Approx 600
sec
Casing BWD600xxx
Max. permissible wire temperature
ϑhot
max. + 600
°C
Approbation
cCSAus (CSA file# 210040)
cURus (UL file# E233422)
(both based on CSA-C22.2
and UL 508)
1): Self protection: At four time type capacity and free convection : Warning
1. No short circuit Mounted in areas without
2. No fault to frame free air change surface
3. Self-extinguishing – no fire temperatures up to
4. No melting of casing 350 degrees Celsius can
be reached.
2): Test conditions: Water jet from nozzle 6,3mm inside diameter, flow rate 12,5l/min +/ 5%, water p- ressure according to volume flow,
distance 2,5-3m, test duration 3min
*Sc = single components
CACR-KL2-240-W1800 | 8164611 [8164613] 2021-08b
