Refer to the numbered drawings which correspond to the paragraph
numbers in the instructions
Introduction 1
Installation 1
Use and safety 3
Cleaning, hygiene and storage 6
Fault nding 6
Maintenance 7
Conformity with regulations 8
GB
1 TR260 GB 08 2024
1.1
2.1
Contents
Introduction
1.1 DESCRIPTION
•
This multi-purpose vegetable cutter can be used to slice, slice
thinly, shred, grate and cut into cubes various food products
(preparation of crudités, vegetables, fruits, cheese, etc.)
With its varied cutting equipment which provides a high hourly
throughput, it is the professional vegetable cutter for community
kitchens and small industrial kitchens.
D Lid locking
E Motor protection casing
F Hopper raising handle
G Automatic hopper
H Feed stick
I Small hopper
J Lever-operated hopper
L Lid hinge pin
A Storage rack
B Press lever
C Electric controls
Installation
2.1 OVERALL DIMENSIONS - WEIGHT (for information only)
•
Dimensions of the machine with auto. hopper
- without table: 750 x 490 x 680
- with table: 750 x 490 x 1345
•
Dimensions of the machine with standard hopper
- without table: 860 x 535 x 615
- with table: 860 x 535 x 1280
•
Handling - Transport
- When packed the machine is meant to be lifted using a forklift
truck or a pallet transporter.
- Where the machine is manually handled on its own, two persons
will be required.
•
Packaged dimensions L x w x h (mm):
- TR260 motor unit: 800 x 520 x 580
- Net weight: 49 kg - Packaged weight: 58 kg
- Auto. hopper: 800 x 520 x 580
- Net weight: 15 kg - packaged weight: 23 kg
- Standard hopper + container: 560 x 490 x 610
- Net weight: 18 kg - Packaged weight: 22 kg
- Cabbage hopper: 560 x 490 x 610
- Net weight: 15 kg - Packaged weight: 19 kg
•
Table packaged dimensions: 750 x 500 x 200
08/2024
Introduction
The User Manual contains useful information for the user on how
to work correctly and in complete safety, and is designed to make
it easier to use the machine (called «machine» or «appliance»
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
to avoid a series of injuries or damage to equipment that might
result from inappropriate procedures for use and management.
It is essential that all the people responsible for transporting,
installing, commissioning, using, maintaining, repairing or dis-
mantling the machine should consult this manual and read it
carefully before proceeding with the various operations, in order
to avoid any incorrect or inappropriate handling that might be
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
is used ready for easy and immediate consultation in case of any
doubt, or in any case, whenever the need arises.
If after reading the Manual, there are still any doubts concerning
how to use the machine, please do not hesitate to contact the
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum eciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
installed must always be applied during all phases of machine
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
The reference language for these instructions is French.
ATTENTION !!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
