Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modifications reserved.
File: V:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\3404440_11013.doc
Erstelldatum/create date: 25.09.2013 10:08:00Aktualisiert/up dated: 23.10.2013
As
special accessories available
:
Mulching blade
Art.-No.: 34.055.65
Spare blade
Art.-No.: 34.055.26
Einhell Grey
Bar code: 4006825 551464
Einhell Grey
Bar code: 4006825 541717
GE-PM 51 S-H B&S
4-in-1 Petrol Lawn Mower
Art.
-
No.
34.044.40
Features
Ergonomic guidance bar with soft grip
Guidance bar 3-settings height adjustable
Fastener on the guidance bar
1 cylinder; 4-stroke-motor Briggs & Stratton
Powder-coated sheet steel housing
Alternatively side throw-off
Alternatively mulch function by mulch cotter
Central cutting height adjustment (6-fold)
Grass collection box with filling level indication
Cleaning position with cleaning tool
Ball bearing wheels
Space-saving storage
Detachable rear wheel drive
Recommended for surfaces up to 1,800 m²
Frontbumper with integrated carrying handle
Technical Data
Motor: 4-stroke-motor, 190 cm³;
B&S 625 E series (124T; XRQ Cover)
Motor Power max.: 2.4 kW (3.3 HP) with 2,800 rpm
Fuel: gasoline (lead free); E10 qualified
Tank volume: 1 liter
Motor oil quantity: 0.6 liter (10W30)
Cutting width: 51 cm
Collection box volume: 70 liter
Central cutting height
adjustment: 6-fold (25 - 75 mm)
Noise level L
WA
:
98 dB
Ignition: contact free (start at the start
tension cable )
Product weight: 39.5 kg
Logistic Data
Net weight: 40.0 kg
Gross weight: 45.5 kg
Packing dimensions: 980 x 620 x 525 mm
Bar code: 4006825 595161
Sales unit: 1 pc
Problemløsning Einhell GE-PM 51 S-H B&S
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Manuel plæneklipper |
| Vægt: | 39500 g |
| Motortype: | Enkeltcylinder OHV |
| Strøm: | 2400 W |
| Strømkilde: | Benzin |
| Kapacitet for brændstoftank: | 1 L |
| Anbefalet klipningsområde: | 1800 m² |
| Klippe-bredde: | - mm |
| Græs-opsamlingsvolumen: | 70 L |
| Minimum klippe-højde: | 25 mm |
| Maksimal klippe-højde: | 75 mm |
| Antal hjul: | 6 hjul |
| Ergonomisk håndtag: | Ja |
| Justerbart håndtag: | Ja |
| Justering af klipperydning: | 6 |
| Klipning, justeringstype: | Trinvis |
| Bioklip funktion: | Ja |
