Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4307400_01019.doc
Erstelldatum/create date: 15.09.2009 11:08:00Aktualisiert/up dated: 25.03.2011
As special accessory available
:
TCT saw blade
Art.-No.: 45.021.58
Ø 127 x Ø 17 mm; 14 teeth
Bar code: 4006825 566604
1
3
7
8
2
4
6
Technical Data
Mains: 230 V ~ 50 Hz
Power: 860 W
Idle speed: 11,000 min
-1
TCT saw blade / teeth: Ø 127 x Ø 17 mm x 2.5 mm/ 14 teeth
Cutting width max: 470 mm
Max. cutting width 45°: 190 mm
Cutting height max.: 18 mm
Net weight: 7.6 kg
Gross weight: 8.7 kg
Packing dimensions: 690 x 375 x 205 mm
Bar code: 4006825 566574
Sales unit: 2 pcs
BT-UP 470
Universal Panel Saw
Art.-No. 43.074.00
Features
Carbide tipped saw blade (1)
Interlock for length cuts (2)
Parallel guide
Clamping device with rubber pad (3)
Precision guidance (4)
Sturdy construction in aluminium pressure
casting (5)
Non-slip rubber caps (6)
Push stick (7)
Dust bag (8)
Angle cuts ranging for 45°, 30°, 20°, 15°
- 10° to 10° every degree
The universal panel saw BT-UP 470 achieves painstaking precision cuts. This is possible by the straight, almost free
from backlash guidance of the saw and the very high speed of the saw blade. By its construction the unit is very
lightweight and thus ideally suitable for assembly working, particularly for all panel working like floor covering, wall
covering, tting straps etc. and cutting types like cutting to length, angle cutting, trimming and measurement cuts to width
(interlock of the drag device).
Problemløsning Einhell BT-UP 470
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 230 V |
| Vekselstrømsindgangsfrekvens: | 50 Hz |
| Bredde: | 375 mm |
| Dybde: | 690 mm |
| Højde: | 205 mm |
| Vægt: | 7600 g |
| Produktfarve: | Rustfrit stål |
| Pakkevægt: | 8700 g |
| Indgangseffekt: | 860 W |
| Tomgang (maks.): | 11000 rpm |
| Certificering: | CE, TÜV GS |
| Blad, diameter: | 127 mm |
| Klinge boring: | 17 mm |
| Savblade inkluderet: | Ja |
| Tomgang: | 11000 rpm |
| Skæredybde (45º): | 190 mm |
| Skæredybe (90º): | 470 mm |
| Blad, tykkelse: | 2.5 mm |
| Antal savtænder: | 14 |
| Spindel bor: | 17 mm |
