Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\1089122_01019.doc
Erstelldatum/create date: 05.05.2009 16:18:00Aktualisiert/up dated: 31.07.2009
Technical data
Mains: 230 V ~ 50 Hz
Charging capacity: 12 V = 0.8 – 25 A arith. / 1.2 – 35 A e
24 V = 1.6 – 17 A arith. / 2.7 – 23 A e.
Jump start feature: 150 A (2 sec)
For lead batteries: min. 3 Ah up to max. 400 Ah
Net weight: 14.8 kg
Gross weight: 16 kg
Packing dimensions: 320 x 260 x 510 mm
Bar code: 4006825562378
Sales unit: 1 pc
BT-
BC 150
Battery Charger
Art.-No. 10.891.22
Features
Construction protection class I
Sheet steel housing (1)
Charging voltage indicator (voltmeter) (2) and charging
current indicator (ampere meter) (3)
Push bar (4)
Charging voltage switch (0 V / 12 V / 24 V) (5)
Charging rate switch (5-position) (6)
3 steps overload- and reverse voltage protection (overload
switch (7), strip fuse (8), thermal protection for transformer)
Integrated cable storage (9)
3 m remote cable with push-button (10)
2 m mains cable with safety plug
2 m charging cable (6 mm
2
) with fully insulated pole
clamps (11)
Rubber feet (12)
Wheels (13)
Powerful and mobile workshop charger for 12 V and 24 V charging voltage and jump start feature. Ideal for workshops
and farmers. Charging capacity can be regulated with 5 settings and the charger is thus also suitable for batteries with a
lower capacity. The integrated smoothing inductor reduces the residual ripple from the recitify charging voltage. It
preserves the battery which will be load and extends compared with rough charging voltage the durability of the battery.
The jump start feature (150A/2s) can be activated with a remote cable (3 metre) by pressing a rocker switch. The large
gauge shows the current charging rate and the charging voltage. The fully insulated pole clamps warrant a perfect
connection to battery poles. The unit is equipped with triple reverse voltage protection and overload protection. The
housing is made of scratch-resistant, powder coated sheet steel housing with a push bar.
4
1
2
3
5
6
10
11
12
13
9
7
8
