Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: V:\Einhell-AG\TP-BK\2013\TL\T-Sek\01-Sek-allgemein\Azubi\PA04-I-No-Wechsel-Anpassung-08-2013\Originale Englisch-Vorgaenger-
Version\4173221_11020.doc
Erstelldatum/create date: 12.06.2008 19:34:00Aktualisiert/up dated: 28.08.2013
As special accessory available:
Suction hose 7 m Art.-No.: 41.736.45 Suction hose 4 m Art.-No.: 41.736.35
Einhell Grey Bar code: 4006825 549102 Einhell Grey Bar code: 4006825 549058
Pre-Filter VF 12 Art.-No.: 41.738.01 Pre-Filter VF 25 Art.-No.: 41.738.51
Einhell Grey Bar code: 4006825 549188 Einhell Grey Bar code: 4006825 549135
Technical Data
Mains: 230 V ~ 50 Hz
Power: 1,100 W
Delivery capacity max.: 4,000 l/h
Delivery height max.: 43 m
Delivery pressure max.: 4.3 bar
Activation pressure max.: 1.5 bar
Cut-o pressure max.: 3 bar
Tank volume: 20 litre
Suction and pressure connection: R 1 (ca. 33.3 mm) female
thread
Water temperature: up to 35 °C
Suction height max.: 8 m
Product weight: 12.85 kg
Gross weight: 15.7 kg
Packing dimensions: 580 x 300 x 530 mm
Bar code: 4006825 549560
BG-WW 1140 NN
Water works
Art.-No. 41.732.21
Features
Water filler screw (1)
Pressure switch (2)
Pressure gauge (3)
Water drain plug (4)
Stainless steel tank 20 ltr. (5)
Stainless steel pump housing (6)
The water works unit pumps water from wells and cisterns automatically with stable water pressure. Toilets, washing
machines and garden watering are just a few of its numerous applications. The housing of the pump and the vessel are
made of corrosion resistant stainless steel, therefore not rusty colouring of the water supplied. The unit is powered by a
sturdy asynchronous motor with thermal protection. The water works is supplied complete with pressure switch and
pressure gauge.
Performance data:
2
1
3
4
6
5
Problemløsning Einhell BG-WW 1140 NN
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 230 V |
| Vekselstrømsindgangsfrekvens: | 50 Hz |
| Produktfarve: | Blue, Silver |
| Strøm: | 1100 W |
| Husmateriale: | Rustfrit stål |
| Maksimalt driftstryk: | 4.3 bar |
| Kabellængde: | 1.5 m |
| Normal brug: | Vandforsyning |
| Maksimal sugehøjde: | 8 m |
| Maksimal leveringshøjde: | 43 m |
| Gennemstrømningshastighed: | 4000 l/t |
| Indslusning: | 1" |
