Side 1/2
Datasheet
DIGITUS Workstation (monitor, keyboard, mouse) Wall
Mount
DA-90451
EAN 4016032486398
Workstation (Monitor, Keyboard, Mouse) Wall Mount 32 inch, 8
kg, VESA 75x75/100x100, white/black
The DIGITUS® Workstation gives you the option of flexible
configuration for a workspace via wall installation. The monitor mount
supports monitors up to 32" (VESA 75x75 / 100x100) with a max.
weight of 8 kg. The shelf for keyboard and mouse also offers a max.
load capacity of 8 kg. Both arms can be individually height adjusted
based on the carrier mount that is installed on the wall.
Universal mount for installation monitor and keyboard/mouse on
the wall with flexible height adjustment
• Monitor arm (gas spring) - 45° inclination, 180° swivel range, VESA
mounts 360° rotation range
• Monitor arm suited for monitors up to 32" and max. weight of 8 kg
(VESA 75x75, 100x100)
• Mount for keyboard & mouse (double hinged arm) - Size: W 60 x D
17.8 cm and handle on the front side
• Double hinged arm with a load capacity of max. 8 kg - Swivel
range up to 180°
• Individual height adjustment of both arms on the carrier mount
(height 73 cm)
• Integrated cable management
• Easy wall installation using three screws
• High-quality aluminum/steel design
• Dimensions:
• Height 73 cm
• Depth: 25-67 cm
• Weight: 4.05 kg
• Color: White/Black
Package contents
• 1x Workspace - wall installation
• 1x Mounting material
• 1x QIG
Logistics
Number
(pcs)
Weight
(kg)
Depth
(cm)
Width
(cm)
Height
(cm)
cm³
Packaging Unit Carton 2 10.28 26.00 78.50 25.00 51,025.00
Packaging Unit Inside 1 5.14 23.50 77.00 11.00 19,904.50
Packaging Unit Single 1 5.14 23.50 77.00 11.00 19,904.50
Net single without Packaging 1 4.05 67.00 60.00 73.00 0.00
More images:
www.digitus.info Druckfehler, Irrtümer und technische Änderungen sind vorbehalten. | Printing errors, falsities and technical changes remain reserved. 1
Problemløsning Digitus DA-90451
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Dybde: | 670 mm |
| Højde: | 730 mm |
| Vægt: | 4050 g |
| Produktfarve: | Black, White |
| Pakkevægt: | 5140 g |
| Pakkedybde: | 235 mm |
| Pakkebredde: | 770 mm |
| Pakkehøjde: | 110 mm |
| Materiale: | Aluminium, Steel |
| Oprindelsesland: | Kina |
| Højdejustering: | Ja |
| Maksimal vægtkapacitet: | 8 kg |
| Drejelig vinkel: | 180 ° |
| Kode i den britiske toldtarif: | 76169990 |
| Pakkevolumen: | 19904.5 cm³ |
| Forbedret kabelstyring: | Ja |
| Maksimal skærmstørrelse kompatibilitet: | 32 " |
| Antal understøttede skærme: | 1 |
| Montering interface kompatibilitet (min.): | 75 x 75 mm |
| Montering interface kompatibilitet (maks.): | 100 x 100 mm |
| Tastaturområde (BxD): | 600 x 178 |
